Leírás és Paraméterek
Technical details:
- Sustainability certificates: Federal Communications Commission (FCC), RoHS, WEEE, CE, REACH, CB
- Lens mount interface: M16
Design:
- Mounting type: Ceiling
- Protection features: Water resistant
- Form factor: Dome
- Product colour: White
- International Protection (IP) code: IP67
- IK code: IK10
- Housing material: Metal
Power:
- Power consumption (Power over Ethernet (PoE)): 9 W
- DC output voltage: 12
- DC output current: 0.6 A
- Power consumption (max): 7.2 W
- Power source type: DC, PoE
Security:
- Password protection: Yes
- Mirror: Yes
- Anti-flicker: Yes
- Heartbeat: Yes
- Privacy protection: Yes
- IP address filtering: Yes
- Automatic Network Replenishment (ANR): Yes
- Pixel counter: Yes
- Password reset via email: Yes
- Digest authentication: Yes
- Video motion detection: Yes
- HTTPS encryption: Yes
- Flash log: Yes
- Audit log: Yes
Operational conditions:
- Storage relative humidity (H-H): 0 - 95%
- Operating temperature (T-T): -30 - 60 °C
- Operating relative humidity (H-H): 0 - 95%
- Storage temperature (T-T): -30 - 60 °C
Management features:
- Web browser: Yes
- Behavior analysis: Intrusion detection, Line crossing detection, Region entrance detection, Region exiting detection
- Web-based management: Yes
- Reset button: Yes
Weight & dimensions:
- Weight: 600 g
- Diameter: 12.1 cm
- Package width: 234 mm
- Height: 97.6 mm
- Package depth: 120 mm
- Package height: 117 mm
Network:
- Live view: Yes
- Number of users: 32 user(s)
- User access level: Administrator, Operator, User
- Number of simultaneous live view channels: 6 channels
- Client interoperability: iVMS-4200, Hik-Connect, Hik-Central
- Quality of Service (QoS) support: Yes
- Ethernet LAN: Yes
- Ethernet interface type: Fast Ethernet
- Wi-Fi: No
- Bluetooth: No
Performance:
- Number of languages: 33
- Dynamic range: 130 dB
- Languages support: Multi
- Placement supported: External / Internal
- Type: IP security camera
- Wide Dynamic Range (WDR): Yes
- Connectivity technology: Wired
Audio:
- Number of microphones: 2
- Built-in microphone: Yes
- Signal-to-Noise Ratio (SNR): 52 dB
Storage:
- Maximum memory card size: 512 GB
- Compatible memory cards: MicroSDXC, MicroSDHC, MicroSD (TransFlash)
- Card reader integrated: Yes
- Built-in HDD: No
Ports & interfaces:
- Line-out: Yes
- Line-in: Yes
- Ethernet LAN (RJ-45) ports: 1
Camera:
- Angle of rotation: 355°
- Pan range: 0 - 355°
- Tilt angle range: 0 - 75°
- Camera shutter speed: 1/100000 s
- Minimum illumination: 0.0001 lx
Image sensor:
- Number of sensors: 1
- Sensor type: CMOS
- Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
- Progressive scan: Yes
Video:
- Image quality adjustment: Brightness, Contrast, Sharpness, Saturation
- Privacy masking: Yes
- Video compression formats: M-JPEG, H.264+, H.264, H.265, H.265+
- Noise reduction technology: 3D noise reduction
- Region of Interest (ROI) encoding: Yes
- Video streaming: Yes
- Frame rate: 30 fps
- Total megapixels: 4 MP
- Maximum resolution: 2688 x 1520 pixels
- Bit rate: 32 Kbps - 8 Mbps
- Supported graphics resolutions: 1920 x 1080 (HD 1080), 640 x 480 (VGA), 2688 x 1520, 640 x 360, 1280 x 720 (HD 720)
- Highlight Compensation (HLC): Yes
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Back Light Compensation (BLC): Yes
Lens system:
- Number of lenses: 1
- Observe distance: 24 m
- Detect distance: 61 m
- Fixed focal length: 2.8 mm
- Recognize distance: 12 m
- Maximum aperture number: 1
