Technical details:
- Iris: Yes
- Lens mount interface: M12
Design:
- Form factor: Dome
- Mounting type: Ceiling/wall
- International Protection (IP) code: IP67
- IK code: IK08
- Product colour: Black
Power:
- Power consumption (max): 5.5 W
- DC output voltage: 12
- Power consumption (Power over Ethernet (PoE)): 7 W
- DC output current: 0.45 A
- Power source type: DC, PoE
Security:
- Alarm input channels: 1
- Alarm output channels: 1
- Intelligent Video Surveillance (IVS) system features: Face detection
- Active tampering alarm: Yes
- Heartbeat: Yes
- Audit log: Yes
- IP address filtering: Yes
- Video motion detection: Yes
- Automatic Network Replenishment (ANR): Yes
- Anti-flicker: Yes
- HTTPS encryption: Yes
- Password protection: Yes
- Pixel counter: Yes
- Password reset via email: Yes
Operational conditions:
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
- Operating temperature (T-T): -30 - 60 °C
- Storage temperature (T-T): -30 - 60 °C
Management features:
- Behavior analysis: Intrusion detection, Line crossing detection
- Reset button: Yes
- Web-based management: Yes
Weight & dimensions:
- Diameter: 11 cm
- Height: 57.4 mm
- Weight: 380 g
Network:
- Ethernet LAN: Yes
- Wi-Fi: No
- Quality of Service (QoS) support: Yes
- Ethernet interface type: Fast Ethernet
- Client interoperability: iVMS-4200, Hik-Connect, Hik-Central
- Number of users: 32 user(s)
- Live view: Yes
- Number of simultaneous live view channels: 6 channels
- User access level: Administrator, Operator, User
- Bluetooth: No
Performance:
- Alarm input/output: Yes
- Languages support: Multi
- Wide Dynamic Range (WDR): Yes
- Day/night mode: Yes
- Dynamic range: 120 dB
- Infrared (IR) cut-off filter: Yes
- Number of languages: 33
- Placement supported: Outdoor
- Connectivity technology: Wired
- Type: IP security camera
Packaging data:
- Package depth: 134 mm
- Package width: 134 mm
- Package height: 108 mm
- Package weight: 615 g
Audio:
- Audio formats supported: AAC, MP3
- Voice codecs: G.711alaw, G.722.1, G.711ulaw, G.726, MP2L2
- Audio input channels: 1.0 channels
- Signal-to-Noise Ratio (SNR): 52 dB
- Sample rates: 8 - 48 kHz
- Bit rate range: 8 - 320 Kbit/s
- Audio output channels: 1.0 channels
- Built-in microphone: Yes
Storage:
- Compatible memory cards: MicroSD (TransFlash)
- Built-in HDD: No
- Maximum memory card size: 256 GB
- Card reader integrated: Yes
Camera:
- Angle of rotation: 360°
- Minimum illumination: 0 lx
- Camera shutter speed: 1/3 - 1/100000 s
- Pan range: -30 - 30°
- Camera tilt control: Yes
- Camera pan control: Yes
- Lens viewing angle, horizontal: 104.3°
- Lens viewing angle, vertical: 55.9°
- Lens viewing angle, diagonal: 123.8°
- Tilt angle range: 0 - 75°
Image sensor:
- Sensor type: CMOS
- Number of sensors: 1
- Optical sensor size: 25.4 / 3 mm (1 / 3")
- Progressive scan: Yes
Video:
- Highlight Compensation (HLC): Yes
- Frame rate: 30 fps
- Image quality adjustment: Sharpness, Contrast, Brightness, Saturation
- Back Light Compensation (BLC): Yes
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Video compression formats: H.265, H.265+, M-JPEG, H.264+, H.264
- Total megapixels: 4 MP
- Noise reduction technology: 3D noise reduction
- Gain control type: Auto
- Bit rate: 32 Kbps - 8 Mbps
- Video streaming: Yes
- Region of Interest (ROI) encoding: Yes
- Noise reduction: Yes
- Maximum resolution: 2688 x 1520 pixels
- Supported graphics resolutions: 2688 x 1520, 1920 x 1080 (HD 1080), 640 x 480 (VGA), 640 x 360, 1280 x 720 (HD 720)
Night vision:
- Night vision: Yes
- LED type: IR
- Infra-red wavelength: 850 nm
- Night vision distance: 30 m
Lens system:
- Fixed focal length: 2.8 mm
- Identify distance: 6 m
- Maximum aperture number: 1.6
- Detect distance: 64 m
- Number of lenses: 1
