Leírás és Paraméterek
Technical details:
- Lens mount interface: M12
- Iris: Yes
Design:
- Form factor: Dome
- Product colour: White
- International Protection (IP) code: IP67
- IK code: IK08
- Housing material: Plastic, Metal
- Mounting type: Ceiling
- Weatherproof: Yes
Power:
- Power source type: DC, PoE
- Power consumption (max): 6 W
- DC output voltage: 12
- DC output current: 0.5 A
- Power consumption (Power over Ethernet (PoE)): 7.5 W
Security:
- Password reset via email: Yes
- Video motion detection: Yes
- Mirror: Yes
- Digital watermark: Yes
- Heartbeat: Yes
- Password protection: Yes
- Active tampering alarm: Yes
Operational conditions:
- Storage temperature (T-T): -30 - 60 °C
- Operating relative humidity (H-H): 0 - 95%
- Operating temperature (T-T): -30 - 60 °C
- Storage relative humidity (H-H): 0 - 95%
Weight & dimensions:
- Weight: 550 g
- Height: 97.6 mm
- Diameter: 12.2 cm
Network:
- Bluetooth: No
- Quality of Service (QoS) support: Yes
- Ethernet LAN: Yes
- Supported network protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP
- Number of simultaneous live view channels: 6 channels
- User access level: Administrator, Operator, User
- Number of users: 32 user(s)
- Wi-Fi: No
- Client interoperability: iVMS-4200, Hik-Connect
- Live view: Yes
Performance:
- Connectivity technology: Wired
- Type: IP security camera
- Wide Dynamic Range (WDR): Yes
- Number of languages: 2
- Day/night mode: Yes
- Placement supported: Indoor & outdoor
- Infrared (IR) cut-off filter: Yes
- Dynamic range: 120 dB
Packaging data:
- Package weight: 800 g
- Package width: 150 mm
- Package height: 141 mm
- Package depth: 150 mm
Audio:
- Built-in microphone: Yes
- Signal-to-Noise Ratio (SNR): 52 dB
- Audio formats supported: G.711 A-law, MP2L2, G.726, PCM, G.722.1, AAC-LC
- Sample rates: 8 - 16 kHz
- Bit rate range: 16 - 160 Kbit/s
Storage:
- Compatible memory cards: MicroSDXC, MicroSDHC, MicroSD (TransFlash)
- Card reader integrated: Yes
- Built-in HDD: No
- Maximum memory card size: 512 GB
Camera:
- Tilt angle range: 0 - 75°
- Minimum illumination: 0 lx
- Angle of rotation: 355°
- Camera shutter speed: 1/3 - 1/100000 s
- Pan range: 0 - 355°
- Lens viewing angle, vertical: 62°
- Lens viewing angle, diagonal: 134°
- Lens viewing angle, horizontal: 113°
Image sensor:
- Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
- Progressive scan: Yes
- Sensor type: CMOS
- Number of sensors: 1
Video:
- Supported graphics resolutions: 640 x 480 (VGA), 640 x 360, 1920 x 1080 (HD 1080), 3860 x 2160, 3200 x 1800, 1280 x 720 (HD 720), 2688 x 1512
- Maximum resolution: 3840 x 2160 pixels
- Noise reduction: Yes
- Bit rate: 32 Kbps - 16 Mbps
- Video compression formats: M-JPEG, H.264+, H.265+, H.265, H.264
- Highlight Compensation (HLC): Yes
- Back Light Compensation (BLC): Yes
- Region of Interest (ROI) encoding: Yes
- Total megapixels: 8 MP
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Noise reduction technology: 3D noise reduction
- Frame rate: 15 fps
- Privacy masking: Yes
- Image quality adjustment: Sharpness, Brightness, White balance, Contrast, Saturation
- Video recording: Yes
Night vision:
- LED type: IR
- Night vision distance: 30 m
- Infra-red wavelength: 850 nm
- Night vision: Yes
Lens system:
- Identify distance: 7 m
- Maximum aperture number: 2
- Observe distance: 31 m
- Detect distance: 79 m
- Recognize distance: 15 m
- Fixed focal length: 2.8 mm
- Number of lenses: 1
