Leírás és Paraméterek
Design:
- Mounting type: Ceiling/Wall/Pole
- Protection features: Dust resistant, Water resistant
- International Protection (IP) code: IP67
- Housing material: Plastic, Metal
- Product colour: White
- Form factor: Turret
Power:
- DC output voltage: 12
- DC output current: 0.66 A
- Power consumption (Power over Ethernet (PoE)): 9.5 W
- Power source type: DC, PoE
- Power consumption (max): 8 W
Security:
- Audit log: Yes
- Digest authentication: Yes
- Heartbeat: Yes
- Mirror: Yes
- Active tampering alarm: Yes
- Password protection: Yes
- Password reset via email: Yes
- Video motion detection: Yes
- Digital watermark: Yes
Operational conditions:
- Storage temperature (T-T): -30 - 60 °C
- Operating temperature (T-T): -30 - 60 °C
- Storage relative humidity (H-H): 0 - 95%
- Operating relative humidity (H-H): 0 - 95%
Weight & dimensions:
- Diameter: 11 cm
- Height: 102.7 mm
- Weight: 385 g
Network:
- User access level: Administrator, Operator, User
- Number of simultaneous live view channels: 6 channels
- Number of users: 32 user(s)
- Wi-Fi: No
- Ethernet interface type: Fast Ethernet
- Supported network protocols: TCP/IP, ICMP, DHCP, DNS, HTTP, RTP, RTSP, NTP, IGMP, IPv6, UDP, QoS, FTP, SMTP, UPnP
- Ethernet LAN: Yes
- Bluetooth: No
- Networking standards: IEEE 802.3af
Performance:
- Languages support: Ukrainian, English
- Placement supported: Indoor & outdoor
- Number of languages: 2
- Day/night mode: Yes
- Infrared (IR) cut-off filter: Yes
- Dynamic range: 120 dB
- Wide Dynamic Range (WDR): Yes
- Connectivity technology: Wired
- Built-in light: Yes
- Type: IP security camera
Packaging data:
- Package weight: 586 g
- Package depth: 150 mm
- Package width: 150 mm
- Package height: 141 mm
Audio:
- Bit rate range: 16 - 160 Kbit/s
- Built-in speaker(s): Yes
- Sample rates: 8 - 16 kHz
- Audio formats supported: AAC-LC, PCM, G.726, MP2L2, G.722.1, G.711
- Signal-to-Noise Ratio (SNR): 52 dB
- Audio system: 2-way
- Built-in microphone: Yes
Storage:
- Compatible memory cards: MicroSDHC, MicroSDXC, MicroSD (TransFlash)
- Maximum memory card size: 512 GB
- Built-in HDD: No
- Card reader integrated: No
Camera:
- Number of Privacy masking areas: 4
- Lens viewing angle, horizontal: 113°
- Lens viewing angle, vertical: 62°
- Lens viewing angle, diagonal: 134°
- Camera shutter speed: 1/3 - 1/100000 s
- Angle of rotation: 360°
- Minimum illumination: 0 lx
- Pan range: 0 - 360°
- Tilt angle range: 0 - 75°
Image sensor:
- Sensor type: CMOS
- Progressive scan: Yes
- Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Video:
- Image quality adjustment: Contrast, Sharpness, Brightness, Saturation
- Video compression formats: M-JPEG, H.265+, H.264+, H.264, H.265
- Bit rate: 32 Kbps - 16 Mbps
- Highlight Compensation (HLC): Yes
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Region of Interest (ROI) encoding: Yes
- Back Light Compensation (BLC): Yes
- Noise reduction technology: 3D noise reduction
- Maximum resolution: 3840 x 2160 pixels
- Total megapixels: 8 MP
- Supported graphics resolutions: 640 x 480 (VGA), 640 x 360, 3200 x 1800, 3840 x 2160, 1920 x 1080 (HD 1080), 2688 x 1520, 1280 x 720 (HD 720)
- Noise reduction: Yes
Night vision:
- Infra-red wavelength: 850 nm
- Night vision: Yes
- Night vision distance: 30 m
- LED type: IR
Lens system:
- Identify distance: 7 m
- Number of lenses: 1
- Recognize distance: 15 m
- Detect distance: 79 m
- Maximum aperture number: 2
- Observe distance: 31 m
- Fixed focal length: 2.8 mm
