Leírás és Paraméterek
Power:
- DC current (max): 3.3 A
- Power consumption (max): 40 W
- Power supply type: DC
- DC voltage: 12 V
Operational conditions:
- Operating temperature (T-T): -10 - 55 °C
- Operating relative humidity (H-H): 10 - 90%
Weight & dimensions:
- Weight: 2 kg
- Width: 384 mm
- Depth: 317 mm
- Height: 52 mm
Network:
- Number of users: 128 user(s)
- Ethernet interface type: Fast Ethernet, Gigabit Ethernet
- Ethernet LAN: Yes
- Ethernet LAN (RJ-45) ports: 1
- Supported network protocols: TCP/IP, PPPoE, DHCP, Hik-Connect, DNS, DDNS, NTP, SADP, NFS, iSCSI, UPnP, HTTPS, ONVIF, ISUP
Performance:
- Audio bitrate: 64 Kbit/s
- Total bandwidth: 256 Mbit/s
- Analog signal format system: NTSC, PAL
- Number of simultaneously playbacked channels: 16 channels
- Video streaming: Yes
- Audio streaming: Yes
- Video compression formats: H.265 Pro+, H.264, H.265, H.264+, H.265 Pro
- Maximum video resolution: 3840 x 2160 pixels
- Audio formats supported: G.711 μ-law
- Rack capacity: 1U
- Internal: No
- Product colour: Black
- Dual stream support: Yes
- Audio input channels: 1 channels
- Maximum frame rate: 30 fps
- USB connectivity: Yes
- Audio output channels: 1.0 channels
- Bit rate: 6000 Kbit/s
Ports & interfaces:
- RS-485 ports: 1
- HDMI ports quantity: 1
- VGA (D-Sub) output ports: 1
- Audio input: 1
- Video input channels: 16 channels
- USB 2.0 ports quantity: 1
- BNC output ports: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- BNC input ports: 16
- Audio output: 1
Hard drive:
- Number of HDDs supported: 2
- Maximum HDD capacity: 12 TB
- Supported HDD interfaces: Serial ATA
