Leírás és Paraméterek
Technical details:
- Product type: Processor
- Number of UPI links: 2
- Supported memory types: DDR4-SDRAM
- Launch date: Q2'19
- Status: Launched
- Memory speed (max): 2400 MHz
- Servicing status: Baseline Servicing
Processor:
- Processor manufacturer: Intel
- Cooler included: No
- Processor ARK ID: 193390
- Thermal Design Power (TDP): 85 W
- Processor base frequency: 2.1 GHz
- Processor generation: 2nd Generation Intel® Xeon® Scalable
- Processor socket: LGA 3647 (Socket P)
- Processor cache: 11 MB
- Processor operating modes: 64-bit
- Processor cores: 8
- Processor model: 4208
- Component for: Server/workstation
- Processor boost frequency: 3.2 GHz
- Processor family: Intel Xeon Silver
- Processor threads: 16
- Processor codename: Cascade Lake
- Processor lithography: 14 nm
- Package type: Box, Tray
Graphics:
- On-board graphics card: No
- Discrete graphics card: No
- Discrete graphics card model: Not available
- On-board graphics card model: Not available
Features:
- Supported instruction sets: SSE4.2, AVX-512, AVX 2.0, AVX
- Scalability: 2S
- Execute Disable Bit: Yes
- Commodity Classification Automated Tracking System (CCATS): G077159
- Export Control Classification Number (ECCN): 5A992C
- PCI Express CEM revision: 3.0
- Market segment: Server
- Embedded options available: No
- PCI Express slots version: 3.0
- Maximum number of PCI Express lanes: 48
Memory:
- Maximum internal memory supported by processor: 1.02 TB
- ECC: Yes
- Memory channels: Hexa-channel
- Memory types supported by processor: DDR4-SDRAM
- Memory clock speeds supported by processor: 2400 MHz
Packaging data:
- Package depth: 137 mm
- Package width: 43 mm
- Package weight: 201 g
- Package height: 112 mm
Processor special features:
- Intel VT-x with Extended Page Tables (EPT): Yes
- Mode-based Execute Control (MBE): Yes
- Intel® vPro™ Platform Eligibility: Yes
- Intel Turbo Boost Max Technology 3.0: No
- Intel TSX-NI: Yes
- Intel® Deep Learning Boost (Intel® DL Boost) on CPU: Yes
- Intel® Resource Director Technology (Intel® RDT): Yes
- Intel® Speed Select technology - Performance Profile (Intel® SST-PP): No
- Intel Speed Select Technology (SST): No
- Intel® Run Sure Technology: No
- Intel® Volume Management Device (VMD): Yes
- AVX-512 Fused Multiply-Add (FMA) units: 1
- Intel 64: Yes
- Intel® Optane™ DC Persistent Memory technology: No
- Intel® Transactional Synchronization Extensions: Yes
- Intel® Speed Shift Technology: Yes
- Intel® Optane™ DC Persistent Memory Supported: No
- Intel® Speed Select Technology - Base Frequency (Intel® SST-BF): No
- Intel Trusted Execution Technology: Yes
- Intel Virtualization Technology for Directed I/O (VT-d): Yes
- Intel Virtualization Technology (VT-x): Yes
- Intel® Turbo Boost Technology: 2.0
- Intel® Hyper Threading Technology (Intel® HT Technology): Yes
- Intel® AES New Instructions (Intel® AES-NI): Yes
- Enhanced Intel SpeedStep Technology: Yes
