Leírás és Paraméterek
Features:
- Built-in display: LCD
- Protection class: AC: III; DC: ll
- DC voltage range: 350 - 650 V
- Maximum AC current: 27.3/26.1 A
- Product colour: White
- Input current: 26 + 13 A
- Rated current: 18.2/17.4 A
- Standard interfaces: RS485, CAN
- MPPT voltage range: 200 - 650 V
- Maximum discharge current: 240 A
- Number of MPP trackers: 2
- Touchscreen: Yes
- Maximum charging current: 240 A
- Starting voltage: 160 V
- International Protection (IP) code: IP65
- Number of phases: 3
- Power current type: DC/AC
- Strings for MPP tracker: 2+1
- Maximum input power (DC): 15600 W
- Maximum PV ISC current: 34 + 17 A
- Rated AC output power: 12000 W
- Nominal input voltage : 550 V
- Maximum continuous AC current: 40 A
- Maximum output power : 13200 W
Security:
- Polarity reverse circuit protection: Yes
- Overvoltage protection: Y
- Overcurrent protection: Yes
- Short circuit protection: Yes
Operational conditions:
- Operating temperature (T-T): -40 - 60 °C
- Noise level: 45 dB
Weight & dimensions:
- Height: 699.3 mm
- Weight: 33.6 kg
- Depth: 279 mm
- Width: 422 mm
