Features:
- Power current type: DC/AC
- Cross-section connections supported: 13 mm²
- Three-phase and parallel operation : Yes
- Power supply type: Indoor/outdoor
- Efficiency: 96%
- Purpose: Solar panel
- Power protection features: Under voltage, Over voltage, Over power, Overheating, Overvoltage protection
- Brand compatibility: Victron Energy
Design:
- Number of VE.Bus ports: 2
- Built-in display: No
- Material: Steel
- Mounting type: M8
- LED indicators: Yes
- Product colour: Blue
Power:
- Peak power: 9000 W
- Input voltage: 38 - 66 V
- Frequency: 50 Hz
- Output voltage: 230 V
- Power at zero load: 18 W
- Output power at 25°C: 4000 W
- Output power at 40°C : 3700 W
- Output power at 65°C : 3000 W
- Apparent power: 5000 VA
- Charging voltage (liquid): 55.2 V
- Charging voltage (absorption) : 57.6 V
- Maximum battery charge current: 70 A
- AC input voltage: 187 - 265 V
- DC input voltage: 48 V
- Frequency range: 45 - 65 Hz
Operational conditions:
- Operating relative humidity (H-H): 0 - 95%
- Operating temperature (T-T): -40 - 65 °C
- International Protection (IP) code: IP22
Weight & dimensions:
- Width: 330 mm
- Depth: 149 mm
- Height: 607 mm
- Weight: 30 kg
