Leírás és Paraméterek
Design:
- SMD Plus: Yes
- International Protection (IP) code: IP67
- Product colour: White
- Degree of protection IK: IK10
- Housing material: Metal, Plastic
- Mounting type: Wall/ceiling
- Form factor: Dome
Power:
- DC output voltage: 12, 48
- Power consumption (max): 5 W
- Power source type: DC, PoE
- Power consumption (Power over Ethernet (PoE)): 6.1 W
- Power consumption (typical): 2.3 W
Operational conditions:
- Operating relative humidity (H-H): 0 - 95%
- Operating temperature (T-T): -40 - 60 °C
Management features:
- Web-based management: Yes
- Web browser: Yes
Weight & dimensions:
- Height: 81 mm
- Weight: 340 g
- Depth: 109.9 mm
- Width: 109.9 mm
Network:
- 4G LTE: No
- Wi-Fi: No
- Ethernet interface type: 10 Megabit Ethernet, 100 Megabit Ethernet
- Bluetooth: No
Performance:
- Connectivity technology: Wired
- Type: IP security camera
- Placement supported: Outdoor
- Signal-to-Noise Ratio (SNR): 56 dB
- Wide Dynamic Range (WDR): 120 dB
Audio:
- Built-in microphone: Yes
- Two-way talk: N
- Built-in loudspeaker: No
- Audio codecs: G.711a, G.711Mu, G.726, PCM
Storage:
- RAM capacity: 256 MB
- ROM capacity: 128 MB
Ports & interfaces:
- Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
- Maximum memory card size: 256 GB
- Number of memory card slots: 1
- Alarm input/output: No
Camera:
- Viewing angle, diagonal: 132°
- Vertical rotation angle: 0 - 65°
- Lens viewing angle, horizontal: 111°
- Camera shutter speed: 1/3 - 1/100000 s
- Horizontal rotation angle: 0 - 355°
- Adjustment shutter speed: Auto/Manual
- Minimum illumination: 0.007 lx
- Lens viewing angle, vertical: 58°
- Motion detection : Yes
- People detection : Yes
Image sensor:
- Number of sensors: 1
- Progressive scan: Yes
- Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
- Sensor type: HD CMOS
Video:
- Total megapixels: 5 MP
- Video compression formats: H.265, H.264H, M-JPEG, H.264+, H.265+, H.264B, H.264
- Frame rate: 20 fps
- Video streaming: Yes
- Maximum resolution: 2960 x 1668 pixels
Night vision:
- LED type: IR
- Number of illumination LEDs: 3
- Night vision: Yes
- Night vision distance: 30 m
Lens system:
- Closest focusing distance: 1.1 m
- Lens type: Fixed focal length lens
- Maximum aperture number: 1.6
- Focal length range: 2.8 mm
- Aperture type: Permanent
- Number of lenses: 1
