Leírás és Paraméterek
Design:
- Housing material: Plastic
- Protection features: Waterproof
- Mounting type: M12
- International Protection (IP) code: IP67
- Product colour: White, Black
Power:
- Power consumption (max): 6.3 W
- DC output voltage: 12
- Power consumption (typical): 1.8 W
- Power consumption (Power over Ethernet (PoE)): 2.3 W
- Power source type: DC, PoE
Security:
- Privacy protection: Yes
- Mirror: Yes
- Video motion detection: Yes
Operational conditions:
- Operating temperature (T-T): -40 - 60 °C
- Storage temperature (T-T): -40 - 60 °C
- Storage relative humidity (H-H): 0 - 95%
- Operating relative humidity (H-H): 0 - 95%
Weight & dimensions:
- Height: 76.2 mm
- Width: 80.2 mm
- Length: 197.9 mm
- Weight: 310 g
Network:
- Ethernet interface type: Fast Ethernet
- Ethernet LAN: Yes
- Number of users: 6 user(s)
- Wi-Fi: No
- Networking standards: IPv6, IPv4
- Bluetooth: No
Performance:
- Type: IP security camera
- Wide Dynamic Range (WDR): Yes
- Placement supported: Indoor & outdoor
- Alarm input/output: Yes
- Built-in light: Yes
- Connectivity technology: Wired
Audio:
- Signal-to-Noise Ratio (SNR): 56 dB
- Voice codecs: G.711Mu, PCM, G.711a, G.726
- Built-in microphone: Yes
Storage:
- Built-in HDD: No
- ROM capacity: 128 MB
- RAM capacity: 128 MB
Camera:
- Adjustment shutter speed: Auto/Manual
- White balance: Street lamp, Auto, Manual, Regional custom, Natural, Outdoor
- Camera shutter speed: 1/3 - 1/100000 s
- Camera shutter type: Auto
- Minimum illumination: 0 lx
- Angle of rotation: 360°
- Lens viewing angle, diagonal: 124°
- Lens viewing angle, horizontal: 104°
- Lens viewing angle, vertical: 55°
- Tilt angle range: 0 - 90°
- Number of Privacy masking areas: 4
Image sensor:
- Progressive scan: Yes
- Sensor type: CMOS
Video:
- Video compression formats: H.264H, H.264, H.265+, H.264+, H.264B, H.265
- Noise reduction: Yes
- Noise reduction technology: 3D NR
- Total megapixels: 2 MP
- Video streaming: Yes
- Region of Interest (ROI) encoding: Yes
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Gain control type: Auto/Manual
- Smart IR: Yes
- Supported graphics resolutions: 640 x 480 (VGA), 1280 x 720, 704 x 480, 1920 x 1080, 352 x 288, 704 x 576, 1280 x 960
- Maximum resolution: 1920 x 1080 pixels
Night vision:
- LED type: IR/White
- Number of illumination LEDs: 2
- Night vision: Yes
Lens system:
- Observe distance: 17.6 m
- Detect distance: 44.1 m
- Recognize distance: 8.8 m
- Fixed focal length: 2.8 mm
- Number of lenses: 1
