Design:
- Product colour: White
- International Protection (IP) code: IP67
- Form factor: Bullet
- Mounting type: Ceiling/wall
Power:
- Power source type: DC, PoE
- Power consumption (max): 6.4 W
- Power consumption (typical): 2 W
- Power over Ethernet (PoE) voltage range: 48 V
- DC output voltage: 12
- Power consumption (Power over Ethernet (PoE)): 2.9 W
Security:
- Video motion detection: Yes
- Active tampering alarm: Yes
- Mirror: Yes
Operational conditions:
- Operating relative humidity (H-H): 0 - 95%
- Operating temperature (T-T): -40 - 60 °C
Management features:
- Smartphone/tablet remote support: Yes
- Management software: Smart PSS, Smart PSS Lite, DSS, DMSS, P2P
- Web browser: Yes
Weight & dimensions:
- Weight: 310 g
- Depth: 197.9 mm
- Width: 80.2 mm
- Height: 76.2 mm
Network:
- Ethernet LAN: Yes
- Wi-Fi: No
- Ethernet interface type: Fast Ethernet
- Supported network protocols: IPv4; IPv6; HTTP; TCP; UDP; ARP; RTP; RTSP; RTCP; RTMP; SMTP; FTP; SFTP; DHCP; DNS; DDNS; NTP; Multicast; ICMP; IGMP; P2P
- Streaming method: Multicast
Performance:
- Connectivity technology: Wired
- Type: IP security camera
- Wide Dynamic Range (WDR): 120 dB
- Day/night mode: Yes
- Placement supported: Indoor & outdoor
Audio:
- Built-in microphone: Yes
- Signal-to-Noise Ratio (SNR): 56 dB
- Audio codecs: G.711a, G.711Mu, G.726, PCM
Storage:
- Internal memory: 128 MB
- ROM capacity: 128 MB
Camera:
- Tilt angle range: 0 - 90°
- Camera shutter type: Auto, Mechanical
- Lens viewing angle, vertical: 52°
- Camera shutter speed: 1/3 -1/100000 s
- White balance: Regional custom, Auto, Outdoor, Natural, Manual, Street lamp
- Pan range: 0 - 360°
- Lens viewing angle, diagonal: 111°
- Lens viewing angle, horizontal: 94°
Image sensor:
- Progressive scan: Yes
- Optical sensor size: 25.4 / 2.9 mm (1 / 2.9")
- Number of sensors: 1
- Sensor type: HD CMOS
- Number of effective pixels (H x V): 2560 x 1440 pixels
Video:
- Supported graphics resolutions: 1920 x 1080 (HD 1080), 2560 x 1440, 704 x 480, 352 x 288, 704 x 576, 1280 x 960, 1280 x 720 (HD 720), 352 x 240, 2304 x 1296, 640 x 480 (VGA)
- Maximum resolution: 2560 x 1440 pixels
- Total megapixels: 4 MP
- Noise reduction technology: 3D NR
- Noise reduction: Yes
- Region of Interest (ROI) encoding: Yes
- Bit rate control: Constant Bit Rate (CBR), Variable Bit Rate (VBR)
- Smart IR: Yes
- Supported video modes: 720p, 1080p, 960p
- Frame rate: 30 fps
- Bit rate: H.264: 32 - 4096Kbps; H.265: 12 - 4096Kbps
- Video compression formats: H.264B, H.264, H.265, H.264+, H.264H, H.265+
- Gain control type: Auto/Manual
- Video streaming: Yes
Night vision:
- LED type: IR / White light LED
- Number of illumination LEDs: 2 / 2
- Night vision distance: 30 m
- Night vision: Yes
Lens system:
- Focal length range: 2.8 mm
- Observe distance: 25.6 m
- Detect distance: 64 m
- Identify distance: 6.4 m
- Recognize distance: 12.8 m
- Closest focusing distance: 1.1 m
- Number of lenses: 1
