Leírás és Paraméterek
Design:
- Form factor: Tube/dome
- International Protection (IP) code: IP67
- Product colour: White
- Housing material: Metal, Plastic
- Mounting type: Wall/ceiling
Power:
- Power consumption (Power over Ethernet (PoE)): 5.5 W
- Power consumption (typical): 2.2 W
- Power source type: DC, PoE
- DC output voltage: 12
- Power consumption (max): 4.6 W
Operational conditions:
- Operating temperature (T-T): -40 - 60 °C
- Storage temperature (T-T): -40 - 60 °C
- Operating relative humidity (H-H): 0 - 95%
Management features:
- Web browser: Yes
- Web-based management: Yes
Weight & dimensions:
- Weight: 480 g
- Height: 70 mm
- Depth: 166.2 mm
- Width: 70 mm
Network:
- Ethernet interface type: 10 Megabit Ethernet, 100 Megabit Ethernet
- 4G LTE: No
- Bluetooth: No
- Wi-Fi: No
- Networking standards: IEEE 802.3af
Performance:
- Placement supported: Outdoor
- Signal-to-Noise Ratio (SNR): 56 dB
- Wide Dynamic Range (WDR): 120 dB
- Connectivity technology: Wired
- Type: IP security camera
Audio:
- Audio codecs: G.711a, G.711Mu, G.726, PCM
- Built-in loudspeaker: No
- Two-way talk: N
- Built-in microphone: Yes
Storage:
- ROM capacity: 128 MB
- RAM capacity: 256 MB
Camera:
- Adjustment shutter speed: Auto/Manual
- People detection : Yes
- Lens viewing angle, vertical: 58°
- Camera shutter speed: 1/3 - 1/100000 s
- Minimum illumination: 0.007 lx
- Lens viewing angle, horizontal: 111°
- Vertical rotation angle: 0 - 90°
- Viewing angle, diagonal: 132°
- Horizontal rotation angle: 0 - 360°
- Motion detection : Yes
Image sensor:
- Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
- Sensor type: HD CMOS
- Progressive scan: Yes
- Number of sensors: 1
Video:
- Maximum resolution: 2960 x 1668 pixels
- Video compression formats: H.264B, H.265+, H.264, H.264+, M-JPEG, H.265, H.264H
- Total megapixels: 5 MP
- Frame rate: 20 fps
- Video streaming: Yes
Night vision:
- LED type: IR / White light LED
- Night vision distance: 30 m
- Night vision: Yes
- Number of illumination LEDs: 1 / 1
Lens system:
- Number of lenses: 1
- Lens type: Fixed focal length lens
- Maximum aperture number: 1.6
- Focal length range: 2.8 mm
- Closest focusing distance: 1.1 m
