Leírás és Paraméterek
Design:
- Housing material: Metal
- Product colour: White
- Mounting type: Ceiling/wall
- Form factor: Tube/dome
- International Protection (IP) code: IP67
Power:
- Power consumption (Power over Ethernet (PoE)): 5.9 W
- Power source type: DC, PoE
- Power consumption (typical): 2.7 W
- DC output voltage: 12
- Power consumption (max): 5 W
Operational conditions:
- Operating relative humidity (H-H): 0 - 95%
- Operating temperature (T-T): -40 - 55 °C
- Storage temperature (T-T): -40 - 55 °C
Management features:
- Web-based management: Yes
- Web browser: Yes
Weight & dimensions:
- Depth: 166.2 mm
- Height: 70 mm
- Width: 70 mm
- Weight: 470 g
Network:
- Networking standards: IEEE 802.3af
- Wi-Fi: No
- Ethernet LAN: Yes
- Bluetooth: No
- Ethernet interface type: Fast Ethernet
- Quality of Service (QoS) support: Yes
- Number of users: 20 user(s)
Performance:
- Connectivity technology: Wired
- Wide Dynamic Range (WDR): 120 dB
- Type: IP security camera
- Placement supported: External / Internal
Audio:
- Audio formats supported: PCM, G.726, G.711Mu, G.711a
- Built-in microphone: Yes
Storage:
- Internal memory: 256 MB
- ROM capacity: 128 MB
- Built-in HDD: No
Camera:
- Lens viewing angle, horizontal: 111°
- Minimum illumination: 0.008 lx
- White balance: Outdoor, Street lamp, Auto, Natural, Manual
- Pan range: 0 - 360°
- Camera shutter speed: 1/3 - 1/100000 s
- Tilt angle range: 0 - 90°
- Adjustment shutter speed: Auto/Manual
- Lens viewing angle, diagonal: 132°
- Lens viewing angle, vertical: 58°
Image sensor:
- Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
- Progressive scan: Yes
- Sensor type: CMOS
- Number of sensors: 1
Video:
- Video compression formats: H.265+, H.264H, H.264, H.265, H.264B, H.264+, M-JPEG
- Noise reduction: Yes
- Supported graphics resolutions: 704 x 576, 1280 x 960, 352 x 240, 2304 x 1296, 352 x 288, 3840 x 2160, 1280 x 720, 2880 x 1620, 704 x 480, 2688 x 1520, 1920 × 1080, 2048 x 1536 (QXGA), 3072 x 1728, 3072 x 2048
- Video streaming: Yes
- Highlight Compensation (HLC): Yes
- Bit rate: H.264: 32 kbps–8192 kbps H.265: 12 kbps–8192 kbps
- Maximum resolution: 3840 x 2160 pixels
- Total megapixels: 8 MP
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Back Light Compensation (BLC): Yes
- Noise reduction technology: 3D noise reduction
- Frame rate: 30 fps
- Gain control type: Auto/Manual
- Region of Interest (ROI) encoding: Yes
Night vision:
- Night vision distance: 30 m
- Number of illumination LEDs: 2
- Night vision: Yes
- LED type: IR / White light LED
Lens system:
- Maximum aperture number: 1.6
- Lens type: Fixed focal length lens
- Closest focusing distance: 1.5 m
- Number of lenses: 1
- Focal length range: 2.8 mm
