Leírás és Paraméterek
Design:
- Mounting type: Ceiling/wall
- Housing material: Plastic, Metal
- International Protection (IP) code: IP67
- Form factor: Bullet
- Product colour: White
Power:
- Power consumption (Power over Ethernet (PoE)): 9.1 W
- Power consumption (max): 7.6 W
- Power consumption (typical): 4.5 W
- DC output voltage: 12
- Power source type: DC, PoE
Security:
- Alarm clock: Yes
- Intelligent Video Surveillance (IVS) system features: Intrusion, Tripwire
- Video motion detection: Yes
- Number of Privacy masking areas (panoramic camera): 8
- Mirror: Yes
- Light effects: Yes
- IP address filtering: Yes
- Sound effects: Yes
- Voice commands: Yes
- LED indicators: Alarm
Operational conditions:
- Storage relative humidity (H-H): 0 - 95%
- Operating temperature (T-T): -40 - 60 °C
- Storage temperature (T-T): -40 - 60 °C
- Operating relative humidity (H-H): 0 - 95%
Weight & dimensions:
- Length: 288.4 mm
- Width: 94.4 mm
- Depth: 84.7 mm
- Weight: 1 kg
- Package weight: 1.23 kg
Network:
- Ethernet interface type: Fast Ethernet
- Number of users: 20 user(s)
- Ethernet LAN: Yes
- Streaming method: Multicast
- Wi-Fi: No
- Bluetooth: No
- Quality of Service (QoS) support: Yes
- Networking standards: IEEE 802.1x, IEEE 802.3af
Performance:
- Placement supported: External / Internal
- Wide Dynamic Range (WDR): 120 dB
- Alarm input/output: Yes
- Day/night mode: Yes
- Type: IP security camera
- Connectivity technology: Wired
Audio:
- Two-way talk: Yes
- Speakerphone: Yes
- Voice codecs: G.723, PCM, G.711Mu, G.711a, G.726
- Number of microphones: 2
- Built-in microphone: Yes
Storage:
- Built-in HDD: No
- Card reader integrated: Yes
- ROM capacity: 128 MB
- Maximum memory card size: 256 GB
- Internal memory: 512 MB
- Compatible memory cards: MicroSD (TransFlash)
Ports & interfaces:
- Audio RCA outputs: 1
- RCA input: 1
- Ethernet LAN (RJ-45) ports: 1
Camera:
- Lens viewing angle, vertical: 55°
- Lens viewing angle, horizontal: 106°
- Camera pan control: Yes
- Camera shutter speed: 1/3 - 1/100000 s
- Maximum frame rate: 30 fps
- White balance: Manual, Natural, Street lamp, Outdoor, Auto, Daylight
- Camera tilt control: Yes
- Lens viewing angle, diagonal: 125°
- Angle of rotation: 360°
- Adjustment shutter speed: Auto/Manual
- Minimum illumination: 0.004 lx
- Pan range: 0 - 360°
- Tilt angle range: 0 - 90°
Image sensor:
- Optical sensor size: 25.4 / 2.8 mm (1 / 2.8")
- Number of sensors: 1
- Sensor type: CMOS
- Progressive scan: Yes
Video:
- Video streaming: Yes
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Privacy masking: Yes
- Gain control type: Auto/Manual
- Noise reduction: Yes
- Total megapixels: 8 MP
- Region of Interest (ROI) encoding: Yes
- Highlight Compensation (HLC): Yes
- Bit rate: H.264: 32 Kbps–8192 Kbps, H.265: 12 Kbps–8192 Kbps
- Back Light Compensation (BLC): Yes
- Noise reduction technology: 3D noise reduction
- Video compression formats: H.264, M-JPEG, H.265+, H.264+, H.265
- Frame rate: 30 fps
- Maximum resolution: 3840 x 2160 pixels
- Supported graphics resolutions: 1920 x 1080 (HD 1080), 2048 x 1536 (QXGA), 3072 x 1728, 704 x 576, 1280 x 960, 352 x 240, 2304 x 1296, 2560 x 1440, 640 x 480 (VGA), 3072 x 2048, 704 x 480, 2688 x 1520, 352 x 288, 3840 x 2160, 2592 x 1944, 1280 x 720 (HD 720)
Night vision:
- Number of illumination LEDs: 4
- Night vision: Yes
- LED type: IR / White light LED
- Night vision distance: 30 m
Lens system:
- Identify distance (wide): 9.1 m
- Maximum aperture number: 1
- Observe distance (wide): 36.4 m
- Closest focusing distance: 2 m
- Detect distance (wide): 91 m
- Number of lenses: 1
- Recognize distance (wide): 18.2 m
- Fixed focal length: 2.8 mm
