Leírás és Paraméterek
Design:
- Product colour: Black
- Mounting type: Ceiling/wall
- Protection features: Water resistant, Dust resistant
- Housing material: Metal
- Form factor: Bullet
- International Protection (IP) code: IP67
Power:
- Power source type: DC, PoE
- DC output voltage: 12
- DC output current: 0.58 A
- Power consumption (max): 8.5 W
Security:
- Security algorithms: TLS, EAP-TLS, EAP-LEAP, EAP-MD5
- Audit log: Yes
- IP address filtering: Yes
- Intelligent Video Surveillance (IVS) system features: Vehicle detection, Region entrance detection, Line crossing detection, Region exiting detection, Human detection, Intrusion, Scene change
- Digest authentication: Yes
- Pixel counter: Yes
- Password reset via email: Yes
- HTTPS encryption: Yes
- Password protection: Yes
- Video motion detection: Yes
- Heartbeat: Yes
- Active tampering alarm: Yes
- Digital watermark: Yes
- Mirror: Yes
Operational conditions:
- Operating temperature (T-T): -30 - 60 °C
- Storage temperature (T-T): -30 - 60 °C
- Storage relative humidity (H-H): 0 - 95%
- Operating relative humidity (H-H): 0 - 95%
Weight & dimensions:
- Weight: 505 g
- Depth: 179.2 mm
- Diameter: 7.44 cm
Network:
- Networking standards: IEEE 802.3af, IEEE 802.1x
- Bluetooth: No
- Number of users: 32 user(s)
- Number of simultaneous live view channels: 6 channels
- User access level: Administrator, Operator, User
- Ethernet LAN: Yes
- Ethernet interface type: Fast Ethernet
- Wi-Fi: No
Performance:
- Connectivity technology: Wired
- Type: IP security camera
- Day/night mode: Yes
- Placement supported: Indoor & outdoor
- Wide Dynamic Range (WDR): Yes
- Infrared (IR) cut-off filter: Yes
- Languages support: Multi
- Dynamic range: 120 dB
Packaging data:
- Package weight: 815 g
- Package width: 234 mm
- Package depth: 120 mm
- Package height: 117 mm
Audio:
- Built-in microphone: Yes
- Audio formats supported: G.722.1, MP2L2, G.726, PCM, MP3, AAC-LC, G.711
- Signal-to-Noise Ratio (SNR): 52 dB
- Bit rate range: 8 - 320 Kbit/s
- Sample rates: 8 - 48 kHz
Storage:
- Built-in HDD: No
- Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
- Card reader integrated: Yes
Camera:
- Tilt angle range: 0 - 90°
- Number of Privacy masking areas: 4
- Lens viewing angle, horizontal: 114.8°
- Lens viewing angle, diagonal: 143.5°
- Lens viewing angle, vertical: 60°
- Pan range: 0 - 360°
- Angle of rotation: 360°
- Minimum illumination: 0 lx
- Camera shutter speed: 1/3 s - 1/100000
Image sensor:
- Sensor type: CMOS
- Progressive scan: Yes
- Optical sensor size: 25.4 / 2.4 mm (1 / 2.4")
Video:
- Supported graphics resolutions: 1920 x 1080 (HD 1080), 640 x 480 (VGA), 2688 x 1520, 640 x 360, 3200 x 1800, 1280 x 720 (HD 720)
- Maximum resolution: 3200 x 1800 pixels
- Video compression formats: H.264+, H.265, H.265+, M-JPEG, H.264
- Region of Interest (ROI) encoding: Yes
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Frame rate: 30 fps
- Noise reduction: Yes
- Noise reduction technology: 3D noise reduction
- Privacy masking: Yes
- Bit rate: 32 Kbps - 16 Mbps
- Image quality adjustment: Brightness, Sharpness, Contrast, Saturation
- Back Light Compensation (BLC): Yes
- Highlight Compensation (HLC): Yes
- Video formats supported: H.264, M-JPEG, H.265, H.265+, H.264+
- Total megapixels: 6 MP
Night vision:
- Night vision: Yes
- Night vision distance: 40 m
- Infra-red wavelength: 850 nm
- LED type: IR
Lens system:
- Maximum aperture number: 1
- Identify distance: 6 m
- Observe distance: 25 m
- Fixed focal length: 2.8 mm
- Recognize distance: 12 m
- Detect distance: 64 m
- Number of lenses: 1
