Leírás és Paraméterek
Design:
- Housing material: Aluminium
- Form factor: Turret
- International Protection (IP) code: IP67
- Product colour: White
- Protection features: Dust resistant, Water resistant
- Mounting type: Ceiling/wall
Power:
- DC output current: 0.6 A
- Power consumption (max): 7.2 W
- Power source type: DC, PoE
- Power consumption (Power over Ethernet (PoE)): 9 W
- DC output voltage: 12
Security:
- Security algorithms: TLS, HTTPS
- Flash log: Yes
- Password protection: Yes
- Network access storage (NAS): Yes
- Automatic Network Replenishment (ANR): Yes
- Audit log: Yes
- Mirror: Yes
- Active tampering alarm: Yes
- Privacy protection: Yes
- Digest authentication: Yes
- Intelligent Video Surveillance (IVS) system features: Face detection
- IP address filtering: Yes
- Heartbeat: Yes
- Video motion detection: Yes
- HTTPS encryption: Yes
- Password reset via email: Yes
- Human and vehicle targets classification: Yes
- Pixel counter: Yes
Operational conditions:
- Storage relative humidity (H-H): 0 - 95%
- Operating temperature (T-T): -30 - 60 °C
- Storage temperature (T-T): -30 - 60 °C
- Operating relative humidity (H-H): 0 - 95%
Management features:
- Web-based management: Yes
- Behavior analysis: Intrusion detection, Line crossing detection
- Reset button: Yes
Weight & dimensions:
- Weight: 550 g
- Height: 115.4 mm
- Diameter: 13.8 cm
Network:
- Bluetooth: No
- Ethernet interface type: Fast Ethernet
- Client interoperability: iVMS-4200, Hik-Connect, Hik-Central
- Wi-Fi: No
- Ethernet LAN: Yes
- Networking standards: IEEE 802.3af
- Quality of Service (QoS) support: Yes
- Live view: Yes
- Number of users: 32 user(s)
- Number of simultaneous live view channels: 6 channels
- User access level: Administrator, Operator, User
Performance:
- Connectivity technology: Wired
- Dynamic range: 120 dB
- Languages support: Multi
- Wide Dynamic Range (WDR): Yes
- Type: IP security camera
- Placement supported: Outdoor
- Day/night mode: Yes
- Number of languages: 33
- Infrared (IR) cut-off filter: Yes
Packaging data:
- Package depth: 170 mm
- Package width: 170 mm
- Package weight: 800 g
- Package height: 160 mm
Audio:
- Signal-to-Noise Ratio (SNR): 52 dB
- Built-in microphone: Yes
- Audio formats supported: PCM, AAC-LC, G.711 A-law, G.722.1, G.711 μ-law, MP3, MP2L2, G.726
- Sample rates: 8 - 48 kHz
- Bit rate range: 8 - 320 Kbit/s
Storage:
- Built-in HDD: No
- Compatible memory cards: MicroSD (TransFlash), MicroSDHC, MicroSDXC
- Card reader integrated: Yes
- Maximum memory card size: 512 GB
Camera:
- Tilt angle range: 0 - 75°
- Minimum illumination: 0 lx
- Camera shutter speed: 1/3 - 1/100000 s
- Angle of rotation: 360°
- Number of Privacy masking areas: 4
- Pan range: 0 - 360°
- Lens viewing angle, horizontal: 100.2°
- Lens viewing angle, diagonal: 119.7°
- Lens viewing angle, vertical: 54.7°
Image sensor:
- Number of sensors: 1
- Progressive scan: Yes
- Optical sensor size: 25.4 / 3 mm (1 / 3")
- Sensor type: CMOS
Video:
- Bit rate: 32 Kbps - 8192 Kbps
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Back Light Compensation (BLC): Yes
- Total megapixels: 4 MP
- Image quality adjustment: Brightness, Sharpness, Contrast, Saturation
- Highlight Compensation (HLC): Yes
- Smart IR: Yes
- Video compression formats: H.265, H.264+, M-JPEG, H.265+, H.264
- Noise reduction technology: 3D noise reduction
- Supported graphics resolutions: 640 x 360, 1280 x 720 (HD 720), 640 x 480 (VGA), 1920 x 1080 (HD 1080), 2688 x 1520
- Video streaming: Yes
- Region of Interest (ROI) encoding: Yes
- Frame rate: 30 fps
- Noise reduction: Yes
- Maximum resolution: 2688 x 1520 pixels
- Privacy masking: Yes
Night vision:
- Infra-red wavelength: 850 nm
- Night vision: Yes
- LED type: IR
- Night vision distance: 30 m
Lens system:
- Number of lenses: 1
- Observe distance: 25 m
- Detect distance: 63 m
- Recognize distance: 12 m
- Fixed focal length: 2.8 mm
- Maximum aperture number: 1
- Identify distance: 6 m
