Leírás és Paraméterek
Technical details:
- Iris: Yes
- Lens mount interface: M16
Design:
- International Protection (IP) code: IP67
- Product colour: White
- Protection features: Water resistant
- Form factor: Bullet
- Mounting type: Ceiling/wall
- Housing material: Metal
Power:
- Power consumption (Power over Ethernet (PoE)): 8 W
- Power source type: DC, PoE
- DC output voltage: 12
- Power consumption (max): 6.5 W
- DC output current: 0.54 A
Security:
- HTTPS encryption: Yes
- Password reset via email: Yes
- Security algorithms: EAP-MD5, TLS, EAP-TLS, EAP-LEAP
- Password protection: Yes
- Human and vehicle targets classification: Yes
- Active tampering alarm: Yes
- Pixel counter: Yes
- Digital watermark: Yes
- Intelligent Video Surveillance (IVS) system features: Face detection
- Digest authentication: Yes
- Privacy protection: Yes
- Network access storage (NAS): Yes
- Video motion detection: Yes
- Heartbeat: Yes
- Alert notification type: E-mail
- Mirror: Yes
- Audit log: Yes
- IP address filtering: Yes
- Automatic Network Replenishment (ANR): Yes
- Flash log: Yes
Operational conditions:
- Operating relative humidity (H-H): 0 - 95%
- Storage relative humidity (H-H): 0 - 95%
- Storage temperature (T-T): -30 - 60 °C
- Operating temperature (T-T): -30 - 60 °C
Management features:
- Web browser: Yes
- Reset button: Yes
- Behavior analysis: Line crossing detection, Region entrance detection, Region exiting detection
Weight & dimensions:
- Weight: 510 g
- Diameter: 7.44 cm
- Length: 179.2 mm
Network:
- User access level: Administrator, Operator, User
- Number of users: 32 user(s)
- Wi-Fi: No
- Bluetooth: No
- Networking standards: IEEE 802.3af, IEEE 802.1x
- Number of simultaneous live view channels: 6 channels
- Ethernet interface type: Fast Ethernet
- Quality of Service (QoS) support: Yes
- Live view: Yes
- Client interoperability: iVMS-4200, Hik-Connect
- Ethernet LAN: Yes
Performance:
- Infrared (IR) cut-off filter: Yes
- Placement supported: Outdoor
- Wide Dynamic Range (WDR): Yes
- Day/night mode: Yes
- Remote viewing: Yes
- Type: IP security camera
- Dynamic range: 130 dB
- Number of languages: 33
- Connectivity technology: Wired
- Languages support: Multi
Packaging data:
- Package depth: 120 mm
- Package weight: 880 g
- Package width: 234 mm
- Package height: 117 mm
Audio:
- Built-in microphone: Yes
- Sample rates: 8 - 48 kHz
- Built-in speaker(s): Yes
- Signal-to-Noise Ratio (SNR): 52 dB
- Audio codecs: G.711/G.722.1/G.726/MP2L2/PCM/MP3/AAC-LC
- Bit rate range: 16 - 320 Kbit/s
Storage:
- Compatible memory cards: MicroSD (TransFlash), MicroSDXC, MicroSDHC
- Maximum memory card size: 512 GB
- Card reader integrated: Yes
- Built-in HDD: No
Camera:
- Lens viewing angle, horizontal: 111.9°
- Pan range: 0 - 360°
- Lens viewing angle, vertical: 60.5°
- Lens viewing angle, diagonal: 133.6°
- Tilt angle range: 0 - 90°
- Minimum illumination: 0 lx
- Number of Privacy masking areas: 4
- Camera shutter speed: 1/3 - 1/100000 s
- Angle of rotation: 360°
Image sensor:
- Progressive scan: Yes
- Optical sensor size: 25.4 / 1.8 mm (1 / 1.8")
- Number of sensors: 1
- Sensor type: CMOS
Video:
- Back Light Compensation (BLC): Yes
- Video compression formats: H.264, H.265+, H.264+, H.265
- Supported graphics resolutions: 1280 x 720 (HD 720), 2688 x 1520, 1920 x 1080 (HD 1080), 640 x 480 (VGA), 640 x 360
- Noise reduction: Yes
- Image quality adjustment: Brightness, Contrast, Saturation, Sharpness
- Frame rate: 30 fps
- Bit rate: 32 Kbps -8 Mbps
- Maximum resolution: 2688 x 1520 pixels
- Noise reduction technology: 3D noise reduction
- Total megapixels: 4 MP
- Region of Interest (ROI) encoding: Yes
- Smart IR: Yes
- Highlight Compensation (HLC): Yes
- Privacy masking: Yes
- Video streaming: Yes
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Gain control type: Auto
Night vision:
- Night vision: Yes
- LED type: IR/White
- Infra-red wavelength: 850 nm
- Night vision distance: 40 m
Lens system:
- Maximum aperture number: 1
- Detect distance: 58.2 m
- Fixed focal length: 2.8 mm
- Fixed focus: Yes
- Number of lenses: 1
- Identify distance: 5.8 m
- Recognize distance: 11.6 m
- Observe distance: 23.1 m
Sustainability:
- Compliance certificates: CB, RoHS, CE, KC
- Sustainability compliance: Yes
