Processor:
- Processor manufacturer: AMD
- Processor socket: Socket AM5
- Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
- Supported processor sockets: Socket AM5
Graphics:
- Maximum resolution: 4096 x 2160 pixels
- Parallel processing technology support: Not supported
- HDCP: Yes
- DirectX version: 12.0
Features:
- Component for: PC
- Motherboard form factor: micro ATX
- Motherboard chipset family: AMD
- Product colour: Dark brown
- Power source type: ATX
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Audio chip: Realtek ALC897
- Cooling type: Passive
- PC health monitoring: Fan, Voltage, Temperature
- Motherboard chipset: AMD B650
Memory:
- Supported memory types: DDR5-SDRAM
- Supported memory clock speed (max): 8000 MHz
- Unbuffered memory: Yes
- Memory channels: Dual-channel
- Supported memory clock speeds: 5200, 6800, 7000, 6000, 6400, 6600, 5600, 7200, 4800, 6200, 7600, 7800, 8000
- Number of memory slots: 4
- Maximum internal memory: 256 GB
- Memory slots type: DIMM
- ECC сompatibility: Non-ECC
- Maximum internal memory per slot: 64 GB
Weight & dimensions:
- Height: 35 mm
- Depth: 244 mm
- Width: 244 mm
Network:
- Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11g, Wi-Fi 6E (802.11ax), 802.11b
- Bluetooth version: 5.3
- Wi-Fi: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
- LAN controller: Realtek RTL8125
- Bluetooth: Yes
- Ethernet LAN: Yes
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- WLAN controller model: Realtek RTL8852CE
Internal I/O:
- Front panel audio connector: Yes
- CPU fan connector: Yes
- Number of SATA III connectors: 4
- EPS power connector (8-pin): Yes
- TPM connector: Yes
- USB 2.0 connectors: 2
- Number of chassis fan connectors: 2
- Front panel connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- RGB LED pin header: Yes
- ATX Power connector (24-pin): Yes
- Number of RGB LED pin headers: 3
- Number of CPU fan connectors: 1
- Number of EPS power connectors (8-pin): 1
BIOS:
- BIOS memory size: 256 Mbit
- System Management BIOS (SMBIOS) version: 2.7
- ACPI version: 5.0
- Clear CMOS jumper: Yes
- BIOS type: UEFI AMI
- Desktop Management Interface (DMI) version: 2.7
Packaging data:
- Package width: 270 mm
- Package depth: 268 mm
- Package weight: 1.53 kg
- Package height: 68 mm
Packaging content:
- Antenna included: Yes
- Screws included: Yes
- Batteries included: Yes
Storage controllers:
- RAID levels: 10, 1, 0
- Supported storage drive types: HDD & SSD
- Number of storage drives supported: 6
- Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
- RAID support: Yes
- Number of HDDs supported: 4
Rear panel I/O ports:
- Line-in: Yes
- Microphone in: Yes
- PS/2 ports quantity: 1
- DisplayPorts quantity: 2
- USB 2.0 ports quantity: 2
- Ethernet LAN (RJ-45) ports: 1
- Headphone outputs: 1
- DisplayPort version: 1.4
- WiFi-AP antenna jack: 2
- HDMI version: 2.1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 2
- PCI Express x1 (Gen 3.x) slots: 1
- 2nd M.2 highest PCI Express generation: 4.0
- 2nd M.2 largest key size: 22110
- 1st M.2 largest key size: 2580
- 1st M.2 highest PCI Express generation: 4.0
Battery:
- Number of battery cells: 1
- Battery type: CR2032
- Battery weight: 3 g
- Battery technology: Lithium-Manganese Dioxide (LiMnO2)
- Lithium weight per battery: 0.07 g
