Processor:
- Supported processor sockets: Socket AM5
- Processor manufacturer: AMD
- Compatible processor series: AMD Ryzen™ 7
- Processor socket: Socket AM5
- Maximum number of SMP processors: 1
- Maximum internal memory supported by processor: 192 GB
Graphics:
- DirectX version: 12.0
- HDCP: Yes
- Parallel processing technology support: Not supported
Features:
- Product colour: Black
- Audio output channels: 7.1 channels
- Motherboard form factor: ATX
- Motherboard chipset: AMD X670
- Motherboard chipset family: AMD
- Windows operating systems supported: Windows 11 x64, Windows 10 Home x64
Memory:
- Supported memory clock speeds: 5200, 7600, 7800, 7000, 6000, 6800, 5600, 7200, 4800, 8000, 6600, 4400 MHz, 6200, 6666, 6400
- Maximum internal memory: 192 GB
- Memory channels: Dual-channel
- Supported memory types: DDR5-SDRAM
- Memory slots type: DIMM
- Number of memory slots: 4
- Supported memory clock speed (max): 8000 MHz
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Width: 305 mm
- Height: 35 mm
- Depth: 269 mm
Network:
- Wi-Fi standards: Wi-Fi 6E (802.11ax), 802.11b, 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n)
- Bluetooth: Yes
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Ethernet interface type: 2.5 Gigabit Ethernet
- Bluetooth version: 5.3
- Wi-Fi: Yes
- Ethernet LAN: Yes
- WLAN controller model: Intel Wi-Fi 6E AX210
Internal I/O:
- Number of SATA III connectors: 6
- USB 2.0 connectors: 2
- Total number of SATA connectors: 6
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Front panel connector: Yes
- CPU fan connector: Yes
- Chassis intrusion connector: Yes
- RGB LED pin header: Yes
- Audio connector: Yes
- USB 3.2 Gen 2x2 connectors: 1
BIOS:
- BIOS type: UEFI AMI
- Clear CMOS jumper: Yes
- Desktop Management Interface (DMI) version: 2.7
Packaging data:
- Package weight: 3.33 kg
- Package height: 430 mm
- Package depth: 335 mm
- Package width: 400 mm
Packaging content:
- Cables included: SATA
- Drivers included: Yes
- Batteries included: Yes
Storage controllers:
- Supported storage drive types: HDD & SSD
- RAID levels: 1, 0, 10
- Supported storage drive interfaces: M.2, SATA II
- Number of storage drives supported: 10
- Number of HDDs supported: 4
Rear panel I/O ports:
- Ethernet LAN (RJ-45) ports: 1
- S/PDIF out port: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 4
- HDMI version: 2.0
- HDMI ports quantity: 1
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
Expansion slots:
- Number of M.2 (M) slots: 4
- PCI Express x4 (Gen 2.x) slots: 1
- PCI Express x1 (Gen 4.x) slots: 1
Battery:
- Battery technology: Lithium-Manganese Dioxide (LiMnO2)
- Battery type: CR2032
- Number of battery cells: 1
- Battery weight: 3 g
- Lithium weight per battery: 0.07 g
Logistics data:
- Country of origin: Taiwan
- Products per shipping (inner) case: 1 pc(s)
