Leírás és Paraméterek
Processor:
- Processor manufacturer: Intel
- Compatible processor series: Intel® Celeron®, Intel® Pentium® Gold
- Processor socket: LGA 1700
Features:
- Motherboard chipset: Intel B760
- Motherboard chipset family: Intel
- Motherboard form factor: ATX
- Audio chip: Realtek ALC897
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Audio output channels: 7.1 channels
Memory:
- Memory channels: Dual-channel
- Maximum internal memory: 192 GB
- Number of memory slots: 4
- Supported memory types: DDR5-SDRAM
- Memory slots type: DIMM
Weight & dimensions:
- Depth: 304.8 mm
- Width: 243.8 mm
Network:
- LAN controller: Dragon RTL8125BG
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Ethernet interface type: 2.5 Gigabit Ethernet
- Ethernet LAN: Yes
- Wi-Fi: Yes
- Bluetooth version: 5.3
- Bluetooth: Yes
Internal I/O:
- S/PDIF out connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 3
- TPM connector: Yes
- Number of SATA III connectors: 4
- USB 2.0 connectors: 4
Storage controllers:
- RAID levels: 1, 0, 10, 5
- Supported storage drive interfaces: M.2, SATA
- RAID support: Yes
Rear panel I/O ports:
- DisplayPort version: 1.4
- HDMI version: 2.1
- HDMI ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- DisplayPorts quantity: 1
- USB 2.0 ports quantity: 4
- S/PDIF out port: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 2
- Number of M.2 (M) slots: 2
- PCI Express x1 (Gen 3.x) slots: 3
- PCI Express x1 slots: 3
- PCI Express x16 slots: 2
