Leírás és Paraméterek
Processor:
- Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
- Processor manufacturer: AMD
- Maximum internal memory supported by processor: 256 GB
- Supported processor sockets: Socket AM5
- Processor socket: Socket AM5
Features:
- Motherboard chipset family: AMD
- Audio output channels: 7.1 channels
- Audio chip: Realtek ALC897
- Windows operating systems supported: Windows 11 x64
- Motherboard form factor: ATX
- Product colour: Black
- Motherboard chipset: AMD B850
Memory:
- Memory channels: Dual-channel
- Supported memory clock speeds: 6000, 5600, 4800, 8200, 6400
- Number of memory slots: 4
- Supported memory clock speed (max): 8200 MHz
- ECC сompatibility: Non-ECC
- Supported memory types: DDR5-SDRAM
- Maximum internal memory: 256 GB
Weight & dimensions:
- Depth: 304.8 mm
- Width: 243.8 mm
Network:
- Bluetooth: Yes
- Wi-Fi standards: Wi-Fi 5 (802.11ac), 802.11n, 802.11b, 802.11a, Wi-Fi 6 (802.11ax), 802.11g, Wi-Fi 6E (802.11ax)
- Ethernet LAN: Yes
- Bluetooth version: 5.3
- Wi-Fi: Yes
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Internal I/O:
- Number of SATA III connectors: 4
- RGB LED pin header: Yes
- TPM connector: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- CPU fan connector: Yes
- USB 2.0 connectors: 4
Storage controllers:
- Supported storage drive types: HDD & SSD
- RAID levels: 10, 1, 0
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
- Number of HDDs supported: 4
Rear panel I/O ports:
- HDMI version: 2.1
- DisplayPorts quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- HDMI ports quantity: 1
- DisplayPort version: 1.4
Expansion slots:
- 1st M.2 highest PCI Express generation: 5.0
- 1st M.2 largest key size: 22110
- Number of M.2 (M) slots: 2
- 2nd M.2 largest key size: 2280
- 2nd M.2 highest PCI Express generation: 4.0
