Leírás és Paraméterek
Processor:
- Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 9000 Series, AMD Ryzen 8000 Series
- Processor socket: Socket AM5
- Processor manufacturer: AMD
- Supported processor sockets: Socket AM5
Features:
- Audio chip: Realtek ALC897
- Motherboard chipset family: AMD
- Audio output channels: 7.1 channels
- Motherboard form factor: micro ATX
- Motherboard chipset: AMD B850
- Product colour: Black
- Windows operating systems supported: Windows 11 x64
Memory:
- ECC сompatibility: Non-ECC
- Supported memory clock speeds: 6400, 4800, 8200
- Maximum internal memory: 256 GB
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Number of memory slots: 4
- Supported memory types: DDR5-SDRAM
- Supported memory clock speed (max): 8200 MHz
Weight & dimensions:
- Depth: 243.8 mm
- Width: 243.8 mm
Network:
- Bluetooth: Yes
- LAN controller: Realtek RTL8126
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), 802.11b, 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), Wi-Fi 4 (802.11n)
- Wi-Fi: Yes
- Bluetooth version: 5.4
- Ethernet interface type: 5 Gigabit Ethernet
- Ethernet LAN: Yes
Internal I/O:
- Number of CPU fan connectors: 2
- Number of RGB LED pin headers: 3
- Number of water pump connectors: 1
- CPU fan connector: Yes
- Number of SATA III connectors: 4
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- USB 2.0 connectors: 4
- Front panel audio connector: Yes
- ATX Power connector (24-pin): Yes
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- Total number of SATA connectors: 4
- Front panel connector: Yes
- RGB LED pin header: Yes
Storage controllers:
- Supported storage drive types: HDD & SSD
- RAID levels: 10, 1, 0
- Supported storage drive interfaces: M.2
- RAID support: Yes
- Number of storage drives supported: 7
- Number of HDDs supported: 4
Rear panel I/O ports:
- Ethernet LAN (RJ-45) ports: 1
- HDMI version: 2.1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
- HDMI ports quantity: 1
Expansion slots:
- 3rd M.2 highest PCI Express generation: 4.0
- 3rd M.2 largest key size: 2280
- 1st M.2 highest PCI Express generation: 5.0
- 2nd M.2 highest PCI Express generation: 5.0
- 2nd M.2 largest key size: 2280
- 1st M.2 largest key size: 2280
- PCI Express x16 (Gen 3.x) slots: 1
- PCI Express x16 slots: 1
- Number of M.2 (M) slots: 3
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x4 slots: 1
- PCI Express x16 (Gen 5.x) slots: 1
