Leírás és Paraméterek
Processor:
- Maximum number of SMP processors: 1
- Compatible processor series: 3rd Generation AMD Ryzen™ 9, 3rd Generation AMD Ryzen™ 3, 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen™ 7
- Processor socket: Socket AM4
- Supported processor sockets: Socket AM4
- Processor manufacturer: AMD
Graphics:
- Parallel processing technology support: 2-Way CrossFireX
- Maximum resolution: 4096 x 2160 pixels
- Maximum graphics card memory: 16000 MB
Features:
- Motherboard chipset family: AMD
- Audio output channels: 7.1 channels
- Motherboard form factor: ATX
- Motherboard chipset: AMD B550
- Number of mounting holes: 9
- Windows operating systems supported: Windows 10 x64
- Audio chip: Realtek ALC1200
Memory:
- Supported memory types: DDR4-SDRAM
- Supported memory clock speeds: 3466, 3000, 5100, 4133, 4000, 3200, 4266, 1866, 2933, 3600, 4733 MHz, 4600, 4533, 2667, 3733, 4400 MHz, 3066, 2400, 2800, 3866, 2133
- Number of memory slots: 4
- Unbuffered memory: Yes
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Maximum internal memory: 128 GB
Weight & dimensions:
- Width: 305 mm
- Depth: 244 mm
Network:
- Wi-Fi: No
- LAN controller: Realtek RTL8111H, Realtek RTL8125B
- Ethernet LAN: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet, Gigabit Ethernet
Internal I/O:
- CPU fan connector: Yes
- Chassis intrusion connector: Yes
- Front panel audio connector: Yes
- USB 2.0 connectors: 2
- Number of SATA III connectors: 6
- 12V power connector: Yes
- RGB LED pin header: Yes
- ATX Power connector (24-pin): Yes
- TPM connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Number of chassis fan connectors: 6
Packaging content:
- Drivers included: Yes
- Cables included: SATA
Storage controllers:
- Supported storage drive types: HDD & SSD
- RAID levels: 0, 1, 10
- Supported storage drive interfaces: SATA III
Rear panel I/O ports:
- PS/2 ports quantity: 1
- Digital audio optical out: 1
- Ethernet LAN (RJ-45) ports: 2
- USB 2.0 ports quantity: 2
- DisplayPorts quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- S/PDIF out port: Yes
- HDMI ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 2
- PCI Express x1 (Gen 3.x) slots: 2
- PCI Express x16 (Gen 3.x) slots: 1
