Leírás és Paraméterek
Processor:
- Compatible processor series: 3rd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen™ 9, 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen™ 3
- Processor socket: Socket AM4
- Maximum number of SMP processors: 1
- Processor manufacturer: AMD
Graphics:
- Maximum graphics card memory: 16000 MB
- Parallel processing technology support: 2-Way CrossFireX
- Maximum resolution: 4096 x 2160 pixels
Features:
- Audio output channels: 7.1 channels
- PC health monitoring: CPU, Temperature, Fan
- Audio chip: Realtek ALC892
- Motherboard chipset family: AMD
- Harmonized System (HS) code: 84733020
- Motherboard form factor: ATX
- Number of mounting holes: 9
- Motherboard chipset: AMD B550
Memory:
- Unbuffered memory: Yes
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Supported memory clock speeds: 3866, 2933, 3600, 3466, 2133, 3000, 1866, 3200, 4266, 2400, 2800, 2667, 3733, 4400, 3066, 4133, 4000
- Maximum internal memory: 128 GB
- Number of memory slots: 4
- Supported memory types: DDR4-SDRAM
Weight & dimensions:
- Height: 65 mm
- Depth: 244 mm
- Width: 305 mm
Network:
- Ethernet interface type: Gigabit Ethernet
- LAN controller: Realtek 8111H
- Wi-Fi: No
- Ethernet LAN: Yes
Internal I/O:
- Number of SATA III connectors: 6
- TPM connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- ATX Power connector (24-pin): Yes
- Chassis intrusion connector: Yes
- CPU fan connector: Yes
- USB 2.0 connectors: 2
- Number of chassis fan connectors: 6
- Front panel audio connector: Yes
- RGB LED pin header: Yes
- 12V power connector: Yes
BIOS:
- Clear CMOS jumper: Yes
- BIOS type: UEFI AMI
Packaging content:
- Cables included: SATA
- Drivers included: Yes
Storage controllers:
- RAID levels: 0, 10, 1
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: SATA III
Rear panel I/O ports:
- DisplayPorts quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- HDMI ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- PS/2 ports quantity: 1
- Digital audio optical out: 1
- S/PDIF out port: Yes
- USB 2.0 ports quantity: 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Expansion slots:
- PCI Express x16 (Gen 3.x) slots: 1
- PCI Express x1 (Gen 3.x) slots: 2
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 2
