Leírás és Paraméterek
Processor:
- Supported processor sockets: Socket AM5
- Maximum number of SMP processors: 1
- Processor socket: Socket AM5
- Processor manufacturer: AMD
- Compatible processor series: AMD Ryzen™ 7
- AMD Opteron series: 7000
Graphics:
- Maximum resolution: 3840 x 2160 pixels
- On-board graphics card: No
Features:
- Audio chip: Realtek ALC897
- Product colour: Black
- Motherboard chipset family: AMD
- Audio output channels: 7.1 channels
- Power source type: ATX
- Cooling type: Active
- Motherboard form factor: micro ATX
- Motherboard chipset: AMD A620
Memory:
- ECC сompatibility: Non-ECC
- Supported memory types: DDR5-SDRAM
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Maximum internal memory: 96 GB
- Supported memory clock speeds: 6000
- Number of memory slots: 2
Weight & dimensions:
- Depth: 243.8 mm
- Width: 211 mm
Network:
- Wi-Fi: No
- Ethernet LAN: Yes
- LAN controller: Realtek RTL8111H
- Ethernet interface type: Gigabit Ethernet
Internal I/O:
- Number of chassis fan connectors: 1
- Chassis intrusion connector: Yes
- ATX Power connector (24-pin): Yes
- TPM connector: Yes
- Power fan connector: Yes
- CPU fan connector: Yes
- Number of COM connectors: 1
- Total number of SATA connectors: 4
- Number of SATA III connectors: 4
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 6
- USB 2.0 connectors: 6
- RGB LED pin header: Yes
Storage controllers:
- RAID levels: 10, 1, 0
- Number of storage drives supported: 5
- Supported storage drive interfaces: M.2, PCI Express, SATA
- RAID support: Yes
- Supported storage drive types: HDD & SSD
Rear panel I/O ports:
- HDMI ports quantity: 1
- Line-in: Yes
- PS/2 ports quantity: 2
- VGA (D-Sub) ports quantity: 1
- Microphone in: Yes
- Ethernet LAN (RJ-45) ports: 1
- USB connector type: USB Type-A
- Headphone outputs: 1
- COM ports quantity: 1
- HDMI version: 2.1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
- USB 2.0 ports quantity: 6
Expansion slots:
- PCI Express x1 slots: 1
- PCI Express x16 slots: 1
- PCI Express x1 (Gen 3.x) slots: 1
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 1
