Leírás és Paraméterek
Processor:
- Compatible processor series: Intel® Core™ i7, Intel® Pentium® Gold, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®
- Processor manufacturer: Intel
- Processor socket: LGA 1700
Features:
- Motherboard form factor: ATX
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Motherboard chipset: Intel B760
- Motherboard chipset family: Intel
- Audio chip: Realtek ALC897
- Audio output channels: 7.1 channels
Memory:
- Unbuffered memory: Yes
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Maximum internal memory: 128 GB
- Supported memory types: DDR4-SDRAM
- Number of memory slots: 4
- Supported memory clock speed (max): 5333 MHz
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Width: 243.8 mm
- Depth: 304.8 mm
Network:
- LAN controller: Realtek RTL8125-BG
- Ethernet interface type: 2.5 Gigabit Ethernet
- Ethernet LAN: Yes
- Wi-Fi: No
Internal I/O:
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 4
- Chassis intrusion connector: Yes
- Number of SATA III connectors: 4
- ATX Power connector (24-pin): Yes
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- Front panel audio connector: Yes
- S/PDIF out connector: Yes
- CPU fan connector: Yes
- Front panel connector: Yes
- USB 2.0 connectors: 4
- Power fan connector: Yes
- 12V power connector: Yes
Packaging content:
- Cables included: SATA
- Drivers included: Yes
Storage controllers:
- RAID support: Yes
- RAID levels: 0, 5, 10, 1
- Supported storage drive interfaces: SATA III
Rear panel I/O ports:
- Ethernet LAN (RJ-45) ports: 1
- DisplayPort version: 1.4
- HDMI ports quantity: 1
- HDMI version: 2.1
- DisplayPorts quantity: 1
- USB 2.0 ports quantity: 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Expansion slots:
- PCI Express x1 (Gen 3.x) slots: 1
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 2
- PCI Express x4 (Gen 4.x) slots: 1
- PCI Express x1 (Gen 4.x) slots: 2
