Leírás és Paraméterek
Design:
- IK code: IK10
- Housing material: Metal
- Protection features: Weatherproof
- International Protection (IP) code: IP67
- Weatherproof: Yes
- Mounting type: Ceiling/wall
- Product colour: White
Power:
- DC output voltage: 12
- Power consumption (Power over Ethernet (PoE)): 12.14 W
- Power source type: DC, PoE
- Power consumption (max): 11.76 W
Security:
- Digest authentication: Yes
- IP address filtering: Yes
- HTTPS encryption: Yes
- Motion sensor: Yes
- Alert notification type: E-mail, Push notification
- Password protection: Yes
- Video motion detection: Yes
- Privacy protection: Yes
Operational conditions:
- Operating temperature (T-T): -30 - 60 °C
- Storage temperature (T-T): -40 - 60 °C
- Storage relative humidity (H-H): 0 - 95%
- Operating relative humidity (H-H): 0 - 95%
Management features:
- Web browser: Yes
- Cloud-managed: Yes
- Reset button: Yes
Weight & dimensions:
- Height: 56 mm
- Diameter: 13.2 cm
- Weight: 440 g
Network:
- Ethernet interface type: Fast Ethernet
- Wi-Fi: No
- Ethernet LAN: Yes
- Supported network protocols: TCP/IP, UDP, ICMP, HTTP, HTTPS, DHCP, DNS, RTSP, NTP, UPnP UDP, SSL/TLS, FTP/SFTP, RTP, IPv4, IPv6, ARP
- Number of simultaneous live view channels: 6 channels
- Client interoperability: Utility, VIGI App, Web UI, VIGI VMS, VIGI Cloud VMS
- Networking standards: IEEE 802.3af, IEEE 802.3u, IEEE 802.3, IEEE 802.3at
- Bluetooth: No
Performance:
- Wide Dynamic Range (WDR): Yes
- Day/night mode: Yes
- Dynamic range: 120 dB
- Infrared (IR) cut-off filter: Yes
- Placement supported: Indoor
- Connectivity technology: Wired
- Type: IP security camera
Audio:
- Bit rate range: 0 - 64 Kbit/s
- Built-in speaker(s): Yes
- Number of microphones: 1
- Signal-to-Noise Ratio (SNR): 52 dB
- Sample rate: 8 kHz
- Built-in microphone: Yes
- Audio system: 2-way
Storage:
- Compatible memory cards: MicroSD (TransFlash)
- Card reader integrated: Yes
- Built-in HDD: No
- Maximum memory card size: 512 GB
Camera:
- Lens viewing angle, diagonal: 180°
- Lens viewing angle, horizontal: 180°
- Minimum illumination: 0 lx
- Number of Privacy masking areas: 4
- Lens viewing angle, vertical: 180°
- Camera shutter speed: 1/3 - 1/10000 s
Image sensor:
- Sensor type: CMOS
- Progressive scan: Yes
- Optical sensor size: 25.4 / 2.7 mm (1 / 2.7")
Video:
- Highlight Compensation (HLC): Yes
- Digital Wide Dynamic Range (DWDR): Yes
- Back Light Compensation (BLC): Yes
- Bit rate: 64 Kbps to 6 Mbps
- Video compression formats: H.264+, H.265+, H.265, H.264
- Video streaming: Yes
- Image quality adjustment: Sharpness, Contrast, Brightness, Saturation
- Frame rate: 30 fps
- Region of Interest (ROI) encoding: Yes
- Total megapixels: 5 MP
- Noise reduction technology: 3D noise reduction
- Bit rate control: Constant Bit Rate (CBR)/Variable Bit Rate (VBR)
- Smart IR: Yes
- Maximum resolution: 2560 x 1920 pixels
- Supported graphics resolutions: 2048 x 1536 (QXGA), 2560 x 1920, 320 x 240, 1280 x 960, 640 x 480 (VGA)
Night vision:
- LED type: IR
- Night vision distance: 10 m
- Number of illumination LEDs: 4
- Night vision: Yes
- Infra-red wavelength: 850 nm
Lens system:
- Recognize distance: 5.7 m
- Fixed focal length: 1.44 mm
- Identify distance: 2.8 m
- Maximum aperture number: 2
- Detect distance: 28.8 m
- Observe distance: 12 m
Panoramic camera:
- Signal-to-Noise Ratio (SNR) (panoramic camera): 52 dB
- Digital Wide Dynamic Range (DWDR) (panoramic camera): Yes
- Sensor type (panoramic camera): CMOS
