Leírás és Paraméterek
Features:
- Product type: Charging regulator
- Voltage monitoring: Yes
- Bluetooth: Yes
- Suitable for: Photovoltaic system
- Temperature sensor: Yes
- Brand compatibility: Victron Energy
- Dedicated application: VictronConnect
Design:
- International Protection (IP) code: IP43
- LED indicators: Yes
- Built-in display: No
- Operating temperature (T-T): -30 - 60 °C
- Cross-section connections supported: 35 mm²
- Product colour: Blue
- VE.Direct port: Yes
- Remote on/off switch: Yes
Power:
- DC battery voltage: 12 / 24 / 48 V
- Rated current: 70 A
- Charging voltage (absorption) : 14,4 / 28,8 / 43,2 / 57,6 V (adjustable)
- Charging voltage (liquid): 13,8 / 27,6 / 41,4 / 55,2 V (adjustable)
- Efficiency: 99%
- Maximum PV open circuit voltage: 250 V
Weight & dimensions:
- Height: 95 mm
- Weight: 3 kg
- Width: 250 mm
- Depth: 185 mm
