Leírás és Paraméterek
Features:
- Programmable: Yes
- Product type: Loader
- Heat protection: Y
- Easy to install: Yes
- Supported battery type: Lead-acid, Lithium
- Suitable for: Photovoltaic system
- Short circuit protection: Yes
- Brand compatibility: Victron Energy
- Dedicated application: VictronConnect
- Fernbedienung: Y
- Parallel connection possible: Unlimited number of devices
Design:
- Conductor cross section: 16 mm²
- International Protection (IP) code: IP43
- LED indicators: Yes
- Product colour: Blue
- Built-in display: No
- Operating temperature (T-T): -20 - 55 °C
- Bluetooth: Yes
- Remote on/off switch: Yes
Power:
- DC battery voltage: 12 / 24 V
- Output current: 20 A
- Input voltage range: 16 - 35 V
- Efficiency: 89%
- Output power at 40°C : 240 W
- Power: 240 W
- Output power at 25°C: 300 W
- Nominal output voltage: 12,2 V
Weight & dimensions:
- Weight: 1.3 kg
- Depth: 130 mm
- Height: 70 mm
- Width: 186 mm
