Leírás és Paraméterek
Features:
- Brand compatibility: Victron Energy
- Suitable for: Photovoltaic system
- Bluetooth: Yes
- Product type: Charging regulator
- Voltage monitoring: Yes
- Automatic load recognition: Yes
- Dedicated application: VictronConnect
Design:
- Product colour: Blue
- International Protection (IP) code: IP43
- Mounting type: MC4
- LED indicators: Yes
- Operating temperature (T-T): -30 - 60 °C
- VE.Direct port: Yes
Power:
- Efficiency: 98%
- Charging voltage (absorption) : 14,4 / 28,8 / 43,2 / 57,6 V (adjustable)
- Charging voltage (liquid): 13,8 / 27,6 / 41,4 / 55,2 V (adjustable)
- Rated current: 70 A
- Maximum PV open circuit voltage: 150 V
- DC battery voltage: 12 / 24 / 48 V
Weight & dimensions:
- Depth: 185 mm
- Weight: 3 kg
- Height: 95 mm
- Width: 250 mm
