Leírás és Paraméterek
Processor:
- Processor manufacturer: AMD
- Compatible processor series: AMD Ryzen 5000 Series, AMD Ryzen 3000 Series
- Processor socket: Socket AM4
- Maximum number of SMP processors: 1
Graphics:
- DirectX version: 12.0
- HDCP: Yes
- Maximum resolution: 4096 x 2160 pixels
- Parallel processing technology support: CrossFireX, Quad-GPU CrossFireX
Features:
- Audio chip: Realtek ALC897
- Motherboard chipset: AMD B550
- Audio output channels: 7.1 channels
- PC health monitoring: Temperature, Voltage, Fan, CPU
- Motherboard chipset family: AMD
- Motherboard form factor: ATX
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
Memory:
- Supported memory clock speeds: 2400, 4133, 4000, 4933, 3466, 3866, 2933, 3600, 4733, 2667, 3733, 4400, 4666, 4533, 2133, 4200, 3800, 4466, 4333, 4600, 3200, 4266
- Maximum internal memory: 128 GB
- Unbuffered memory: Yes
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Number of memory slots: 4
- Supported memory types: DDR4-SDRAM
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Width: 305 mm
- Depth: 244 mm
- Height: 330 mm
Network:
- LAN controller: Killer E3100G
- Wake-on-LAN ready: Yes
- Wi-Fi: No
- Ethernet LAN: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- Thunderbolt headers: 1
- TPM connector: Yes
- CPU fan connector: Yes
- USB 2.0 connectors: 3
- Front panel audio connector: Yes
- ATX Power connector (24-pin): Yes
- Number of SATA III connectors: 6
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Number of chassis fan connectors: 5
- 12V power connector: Yes
- RGB LED pin header: Yes
Packaging content:
- Cables included: SATA
- Drivers included: Yes
Storage controllers:
- Supported storage drive interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- RAID levels: 10, 1, 0
- RAID support: Yes
Rear panel I/O ports:
- S/PDIF out port: Yes
- Digital audio optical out: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 6
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- HDMI version: 2.1
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- PS/2 ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
Expansion slots:
- PCI Express x16 slots: 3
- PCI Express x1 (Gen 3.x) slots: 1
- Number of M.2 (M) slots: 2
