Leírás és Paraméterek
Processor:
- Compatible processor series: Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®
- Processor manufacturer: Intel
- Processor socket: LGA 1700
- Supported processor sockets: LGA 1700
Graphics:
- Parallel processing technology support: Not supported
- Maximum resolution: 4096 x 2304 pixels
- HDCP: Yes
Features:
- Audio output channels: 7.1 channels
- PC health monitoring: Voltage, Temperature, Water cooling, Fan
- Power source type: ATX
- Motherboard form factor: micro ATX
- Motherboard chipset family: Intel
- Windows operating systems supported: Windows 11, Windows 10
Memory:
- Supported memory clock speeds: 4300, 4400, 2933, 3300, 3333, 2133, 3400, 3866, 3000, 2400, 4700, 4500, 3200, 2666, 4266, 4133, 4000, 4800, 4933, 4600
- Memory slots type: DIMM
- Memory channels: Dual-channel
- Supported memory types: DDR4-SDRAM
- Unbuffered memory: Yes
- Maximum internal memory: 128 GB
- Number of memory slots: 4
- Supported memory clock speed (max): 4933 MHz
Weight & dimensions:
- Depth: 244 mm
- Width: 244 mm
Network:
- Ethernet LAN: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- S/PDIF out connector: Yes
- RGB LED pin header: Yes
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- TPM connector: Yes
- Thunderbolt headers: 2
- ATX Power connector (24-pin): Yes
- Front panel connector: Yes
- Number of SATA III connectors: 4
- USB 2.0 connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Number of chassis fan connectors: 3
- EPS power connector (8-pin): Yes
- CPU fan connector: Yes
- Serial port headers: 1
- Front panel audio connector: Yes
BIOS:
- Clear CMOS jumper: Yes
- Desktop Management Interface (DMI) version: 2.7
- BIOS type: UEFI AMI
Storage controllers:
- Supported storage drive interfaces: M.2, SATA III
- Number of storage drives supported: 6
- Supported storage drive types: HDD & SSD
- RAID support: Yes
- RAID levels: 5, 10, 0, 1
Rear panel I/O ports:
- Line-in: Yes
- Microphone in: Yes
- Headphone outputs: 1
- HDMI ports quantity: 1
- HDMI version: 2.0
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- DisplayPorts quantity: 1
- USB 2.0 ports quantity: 5
- Ethernet LAN (RJ-45) ports: 1
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 1
- PCI Express x16 (Gen 3.x) slots: 1
