Leírás és Paraméterek
Processor:
- Compatible processor series: Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9, Intel® Core™ i3
- Processor manufacturer: Intel
- Processor socket: LGA 1700
- Maximum number of SMP processors: 1
Features:
- Motherboard chipset: Intel B760
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Motherboard chipset family: Intel
- Audio chip: Realtek ALC897
- Audio output channels: 7.1 channels
- Motherboard form factor: micro ATX
Memory:
- Unbuffered memory: Yes
- Number of memory slots: 2
- Memory slots type: DIMM
- Maximum internal memory: 96 GB
- Supported memory types: DDR5-SDRAM
Weight & dimensions:
- Depth: 201 mm
- Width: 244 mm
Network:
- LAN controller: Dragon RTL8125BG
- Ethernet interface type: Gigabit Ethernet
- Ethernet LAN: Yes
- Wi-Fi: Yes (Requires antenna)
Internal I/O:
- Number of SATA III connectors: 4
- USB 2.0 connectors: 2
- Front panel audio connector: Yes
- CPU fan connector: Yes
- TPM connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- ATX Power connector (24-pin): Yes
- LED connector: Y
- 12V power connector (8-pin): Y
Storage controllers:
- Supported storage drive interfaces: M.2, SATA III
- RAID levels: 1, 10, 0, 5
- Supported storage drive types: HDD & SSD
- RAID support: Yes
Rear panel I/O ports:
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 2
- Number of audio jack connectors: 3
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- HDMI ports quantity: 2
- WiFi-AP antenna jack: 2
Expansion slots:
- PCI Express x1 (Gen 3.x) slots: 2
- Number of M.2 (M) slots: 1
- PCI Express x16 (Gen 4.x) slots: 1
