Leírás és Paraméterek
Processor:
- Compatible processor series: 3rd Generation AMD Ryzen™ 9, AMD Ryzen™ 7, AMD Ryzen™ 5
- Processor socket: Socket AM4
- Processor manufacturer: AMD
- Maximum number of SMP processors: 1
Graphics:
- Maximum resolution: 4096 x 2160 pixels
- Parallel processing technology support: Not supported
Features:
- Motherboard chipset family: AMD
- Motherboard chipset: AMD B550
- Motherboard form factor: micro ATX
- Audio output channels: 7.1 channels
Memory:
- Supported memory clock speeds: 3866, 3466, 2667, 3733, 4400, 3066, 2400, 2800, 3200, 4266, 2933, 3600, 3000, 4133, 4000, 2133, 1866
- Maximum internal memory: 128 GB
- Memory slots type: DIMM
- Memory channels: Dual-channel
- Number of memory slots: 4
- Unbuffered memory: Yes
- Supported memory types: DDR4-SDRAM
Weight & dimensions:
- Depth: 244 mm
- Width: 244 mm
Network:
- Wi-Fi: No
- LAN controller: Realtek 8111HN
- Ethernet interface type: Gigabit Ethernet
- Ethernet LAN: Yes
Internal I/O:
- USB 2.0 connectors: 2
- TPM connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Number of SATA III connectors: 4
- Front panel audio connector: Yes
- 12V power connector: Yes
- RGB LED pin header: Yes
- Front panel connector: Yes
- ATX Power connector (24-pin): Yes
- Chassis intrusion connector: Yes
- Number of chassis fan connectors: 3
- Serial port headers: 1
- CPU fan connector: Yes
Packaging content:
- Drivers included: Yes
- Cables included: SATA
Storage controllers:
- Supported storage drive types: HDD & SSD
- RAID levels: 1, 0, 10
- Supported storage drive interfaces: Serial ATA III
Rear panel I/O ports:
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- VGA (D-Sub) ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- DisplayPorts quantity: 1
- HDMI version: 2.1
- HDMI ports quantity: 1
- USB 2.0 ports quantity: 2
Expansion slots:
- Number of M.2 (M) slots: 2
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x1 (Gen 3.x) slots: 2
