Leírás és Paraméterek
Processor:
- Compatible processor series: Intel Core i9 14th Gen, Intel Core i3 12th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i7 13th Gen, Intel Core i5 12th Gen, Intel Core i9 13th Gen, Intel Core i7 12th Gen, Intel Core i3 13th Gen
- Processor socket: LGA 1700
- Processor manufacturer: Intel
Features:
- Audio output channels: 7.1 channels
- Motherboard chipset: Intel B760
- Motherboard chipset family: Intel
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
- Audio chip: Realtek ALC897
- Motherboard form factor: micro ATX
Memory:
- Supported memory types: DDR5-SDRAM
- Number of memory slots: 2
- Memory slots type: DIMM
- Memory channels: Dual-channel
- ECC сompatibility: Non-ECC
- Maximum internal memory: 96 GB
- Unbuffered memory: Yes
Weight & dimensions:
- Depth: 201 mm
- Width: 244 mm
Network:
- Wi-Fi: No
- Ethernet LAN: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
- LAN controller: Dragon RTL8125BG
Internal I/O:
- RGB LED pin header: Yes
- Front panel audio connector: Yes
- CPU fan connector: Yes
- Number of SATA III connectors: 4
- ATX Power connector (24-pin): Yes
- TPM connector: Yes
- USB 2.0 connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
Packaging content:
- Cables included: SATA
- Screws included: Yes
Storage controllers:
- RAID levels: 1, 5, 10, 0
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
Rear panel I/O ports:
- Microphone in: Yes
- Line-in: Yes
- VGA (D-Sub) ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- Ethernet LAN (RJ-45) ports: 1
- DisplayPort version: 1.4
- USB 2.0 ports quantity: 2
- DisplayPorts quantity: 1
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x1 (Gen 3.x) slots: 2
- Number of M.2 (M) slots: 1
