Leírás és Paraméterek
Processor:
- Compatible processor series: Intel Core i3 12th Gen, Intel Core i3 14th Gen, Intel Core i3 13th Gen, Intel Core i5 14th Gen, Intel Core i5 13th Gen, Intel Core i5 12th Gen
- Processor manufacturer: Intel
- Processor socket: LGA 1700
Features:
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
- Audio chip: Realtek ALC897
- Motherboard chipset family: Intel
- Audio output channels: 7.1 channels
- Motherboard form factor: micro ATX
- Motherboard chipset: Intel B760
Memory:
- Memory channels: Dual-channel
- Supported memory types: DDR5-SDRAM
- Memory slots type: SO-DIMM
- Number of memory slots: 2
- Maximum internal memory: 128 GB
- Supported memory clock speeds: 7200
- Unbuffered memory: Yes
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Depth: 221 mm
- Width: 244 mm
Network:
- Ethernet LAN: Yes
- Ethernet interface type: 2.5 Gigabit Ethernet
- Wi-Fi: No
- LAN controller: Dragon RTL8125BG
Internal I/O:
- RGB LED pin header: Yes
- TPM connector: Yes
- Number of SATA III connectors: 4
- USB 2.0 connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Front panel audio connector: Yes
- EPS power connector (8-pin): Yes
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
Storage controllers:
- Supported storage drive interfaces: SATA III, M.2
- RAID support: Yes
- RAID levels: 0, 1, 10, 5
Rear panel I/O ports:
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 3
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
- DisplayPorts quantity: 1
- DisplayPort version: 1.4
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 2
Expansion slots:
- PCI Express x16 (Gen 5.x) slots: 1
- Number of M.2 (M) slots: 1
- PCI Express x1 (Gen 3.x) slots: 1
