Processor:
- Compatible processor series: AMD Ryzen 7000 Series, AMD Ryzen 8000 Series, AMD Ryzen 9000 Series
- Supported processor sockets: Socket AM5
- Processor manufacturer: AMD
- Processor socket: Socket AM5
Graphics:
- Maximum resolution: 3840 x 2160 pixels
- Parallel processing technology support: Not supported
- HDCP: Yes
Features:
- Motherboard chipset family: AMD
- Product colour: Black
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
- Audio chip: Realtek ALC897
- Motherboard form factor: ATX
- Audio output channels: 7.1 channels
- Motherboard chipset: AMD B850
Memory:
- ECC сompatibility: ECC & Non-ECC
- Unbuffered memory: Yes
- Maximum internal memory: 256 GB
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Supported memory types: DDR5-SDRAM
- Number of memory slots: 4
Weight & dimensions:
- Width: 305 mm
- Depth: 244 mm
Network:
- LAN controller: Dragon RTL8125BG
- Wi-Fi: No
- Ethernet interface type: 2.5 Gigabit Ethernet
- Ethernet LAN: Yes
Internal I/O:
- Number of water pump connectors: 1
- Number of RGB LED pin headers: 4
- Number of CPU fan connectors: 2
- Number of EPS power connectors (8-pin): 2
- Number of chassis fan connectors: 4
- ATX Power connector (24-pin): Yes
- TPM connector: Yes
- Number of SATA III connectors: 4
- CPU fan connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- USB 2.0 connectors: 2
- Front panel audio connector: Yes
- EPS power connector (8-pin): Yes
- 12V power connector: Yes
- RGB LED pin header: Yes
- USB 3.2 Gen 2x2 connectors: 1
Packaging content:
- Cables included: SATA
- Screws included: Yes
Storage controllers:
- Supported storage drive types: HDD & SSD
- RAID levels: 10, 1, 0
- RAID support: Yes
- Number of storage drives supported: 8
- Supported storage drive interfaces: PCI Express 3.0, PCI Express 4.0, PCI Express 5.0, SATA III
Rear panel I/O ports:
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- USB connector type: USB Type-A, USB Type-C
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 6
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- HDMI version: 2.1
- Microphone in: Yes
- Line-in: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
- Headphone outputs: 3
Expansion slots:
- 1st M.2 largest key size: 2280
- 3rd M.2 highest PCI Express generation: 4.0
- 4th M.2 largest key size: 2280
- 3rd M.2 largest key size: 2280
- 4th M.2 highest PCI Express generation: 3.0
- 2nd M.2 highest PCI Express generation: 4.0
- 2nd M.2 largest key size: 2280
- 1st M.2 highest PCI Express generation: 5.0
- Number of M.2 (M) slots: 4
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x16 (Gen 5.x) slots: 1
