Leírás és Paraméterek
Processor:
- Compatible processor series: Intel® Core™ i3, Intel® Core™ i5, Intel® Core™ i7, Intel® Core™ i9
- Processor manufacturer: Intel
- Maximum number of SMP processors: 1
- Processor socket: LGA 1200
Features:
- Audio output channels: 7.1 channels
- Motherboard form factor: micro ATX
- Motherboard chipset: Intel H470
- Audio chip: Realtek ALC897
Memory:
- Supported memory types: DDR4-SDRAM
- Number of memory slots: 2
- Maximum internal memory: 64 GB
- Supported memory clock speeds: 2666, 2400, 2800, 2933, 2133
- Memory channels: Dual-channel
- Memory slots type: DIMM
Weight & dimensions:
- Depth: 198 mm
- Width: 231 mm
Network:
- LAN controller: Realtek 8111H
- Wi-Fi: No
- Ethernet LAN: Yes
- Ethernet interface type: Gigabit Ethernet
Internal I/O:
- Number of SATA III connectors: 4
- Front panel audio connector: Yes
- CPU fan connector: Yes
- TPM connector: Yes
- USB 2.0 connectors: 2
- ATX Power connector (24-pin): Yes
- Number of COM connectors: 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- 12V power connector (8-pin): Y
Storage controllers:
- Supported storage drive interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- Number of HDDs supported: 4
Rear panel I/O ports:
- Ethernet LAN (RJ-45) ports: 1
- DVI-D ports quantity: 1
- USB 2.0 ports quantity: 2
- PS/2 ports quantity: 2
- VGA (D-Sub) ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- HDMI ports quantity: 1
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x1 (Gen 3.x) slots: 1
