Leírás és Paraméterek
Processor:
- Compatible processor series: Intel® Core™ i3, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i5, Intel® Celeron®
- Processor manufacturer: Intel
- Processor socket: LGA 1200 (Socket H5)
Features:
- Windows operating systems supported: Windows 10 x64
- Motherboard chipset: Intel H510
- Audio output channels: 7.1 channels
- Motherboard chipset family: Intel
- Motherboard form factor: micro ATX
Memory:
- Supported memory types: DDR4-SDRAM
- Memory slots type: DIMM
- Maximum internal memory: 64 GB
- Supported memory clock speeds: 3200, 2666, 2133, 3000, 2933, 2400, 2800
- Memory channels: Dual-channel
- Unbuffered memory: Yes
- Number of memory slots: 2
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Width: 226 mm
- Depth: 203 mm
Network:
- Ethernet LAN: Yes
- Ethernet interface type: Gigabit Ethernet, Fast Ethernet
- Wi-Fi: No
Internal I/O:
- S/PDIF out connector: Yes
- Number of SATA III connectors: 4
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- TPM connector: Yes
- EPS power connector (8-pin): Yes
- Number of chassis fan connectors: 1
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- Front panel audio connector: Yes
- 12V power connector: Yes
- USB 2.0 connectors: 2
Storage controllers:
- Supported storage drive interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- Number of HDDs supported: 4
- Number of storage drives supported: 5
Rear panel I/O ports:
- USB 2.0 ports quantity: 2
- VGA (D-Sub) ports quantity: 1
- COM ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- HDMI ports quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- PS/2 ports quantity: 1
Expansion slots:
- Number of M.2 (M) slots: 1
- PCI Express x1 (Gen 3.x) slots: 1
