Leírás és Paraméterek
Processor:
- Supported processor sockets: Socket AM5
- Compatible processor series: AMD Ryzen 7000 Series
- Processor manufacturer: AMD
- Processor socket: Socket AM5
Features:
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 11 x64, Windows 10 x64
- Component for: PC
- Motherboard chipset family: AMD
- Motherboard form factor: micro ATX
- Motherboard chipset: AMD B650
Memory:
- Supported memory clock speeds: 5600, 6000, 6200, 5000, 4800, 6400, 5200, 5800, 5400
- Unbuffered memory: Yes
- ECC сompatibility: ECC & Non-ECC
- Supported memory types: DDR5-SDRAM
- Memory slots type: DIMM
- Number of memory slots: 4
- Memory channels: Dual-channel
Weight & dimensions:
- Width: 244 mm
- Depth: 244 mm
- Height: 50 mm
Network:
- Bluetooth: Yes
- Bluetooth version: 5.2
- Ethernet interface type: Fast Ethernet, 2.5 Gigabit Ethernet, Gigabit Ethernet
- Wi-Fi standards: Wi-Fi 4 (802.11n), 802.11g, 802.11b, Wi-Fi 5 (802.11ac), 802.11a, Wi-Fi 6 (802.11ax)
- Top Wi-Fi standard: Wi-Fi 6 (802.11ax)
- Ethernet LAN: Yes
- Wi-Fi: Yes
Internal I/O:
- CPU fan connector: Yes
- S/PDIF out connector: Yes
- USB 2.0 connectors: 2
- Number of SATA III connectors: 4
- EPS power connector (8-pin): Yes
- TPM connector: Yes
- Front panel audio connector: Yes
- ATX Power connector (24-pin): Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Number of chassis fan connectors: 3
- Number of COM connectors: 1
- RGB LED pin header: Yes
BIOS:
- BIOS memory size: 256 Mbit
- BIOS type: UEFI AMI
Packaging data:
- Package depth: 265 mm
- Package width: 280 mm
- Package weight: 1.34 kg
- Package height: 71 mm
Storage controllers:
- RAID levels: 0, 10, 1
- Supported storage drive types: HDD & SSD
- RAID support: Yes
- Supported storage drive interfaces: M.2, SATA III
- Number of storage drives supported: 6
Rear panel I/O ports:
- DisplayPorts quantity: 1
- USB 2.0 ports quantity: 4
- Ethernet LAN (RJ-45) ports: 1
- Line-in: Yes
- PS/2 ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- VGA (D-Sub) ports quantity: 1
- HDMI ports quantity: 1
- Microphone in: Yes
Expansion slots:
- Number of M.2 (M) slots: 2
- PCI Express x16 (Gen 4.x) slots: 3
