Leírás és Paraméterek
Processor:
- Compatible processor series: Intel® Core™ i3, Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold
- Supported processor sockets: LGA 1700
- Processor manufacturer: Intel
- Processor socket: LGA 1700
Features:
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Component for: PC
- Motherboard form factor: ATX
- Audio output channels: 7.1 channels
- Motherboard chipset family: Intel
- Motherboard chipset: Intel B760
Memory:
- Memory channels: Dual-channel
- Supported memory types: DDR5-SDRAM
- Number of memory slots: 4
- Memory slots type: DIMM
- Maximum internal memory: 128 GB
- Unbuffered memory: Yes
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Height: 50 mm
- Width: 305 mm
- Depth: 244 mm
Network:
- Wi-Fi: No
- Ethernet interface type: 2.5 Gigabit Ethernet
- Ethernet LAN: Yes
Internal I/O:
- CPU fan connector: Yes
- Number of COM connectors: 1
- 12V power connector: Yes
- Front panel connector: Yes
- TPM connector: Yes
- EPS power connector (8-pin): Yes
- RGB LED pin header: Yes
- Number of chassis fan connectors: 4
- USB 2.0 connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Number of SATA III connectors: 4
- Front panel audio connector: Yes
- Thunderbolt headers: 1
- ATX Power connector (24-pin): Yes
BIOS:
- BIOS memory size: 128 Mbit
- Clear CMOS button: Yes
Packaging data:
- Package height: 68 mm
- Package width: 338 mm
- Package depth: 273 mm
- Package weight: 2.43 kg
Storage controllers:
- RAID levels: 10, 1, 0, 5
- Supported storage drive interfaces: M.2, SATA III
- Supported storage drive types: HDD & SSD
- RAID support: Yes
Rear panel I/O ports:
- HDMI ports quantity: 1
- Microphone in: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- Headphone outputs: 1
- Line-in: Yes
- Ethernet LAN (RJ-45) ports: 1
- DisplayPorts quantity: 1
- USB 2.0 ports quantity: 4
- S/PDIF out port: Yes
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 3
- PCI Express x1 (Gen 3.x) slots: 1
