Leírás és Paraméterek
Processor:
- Compatible processor series: Intel® Core™ i3, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i5, Intel® Celeron®
- Processor socket: LGA 1700
- Processor manufacturer: Intel
- Supported processor sockets: LGA 1700
Features:
- Motherboard chipset: Intel B760
- Motherboard form factor: micro ATX
- Motherboard chipset family: Intel
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 10 x64, Windows 11
Memory:
- Unbuffered memory: Yes
- Supported memory clock speeds: 5000, 5200, 4800, 5600, 7200, 6400, 6800, 6600, 6000, 5800, 5400, 6200, 7000
- Maximum internal memory: 192 GB
- Memory slots type: DIMM
- Number of memory slots: 4
- Supported memory types: DDR5-SDRAM
- Memory channels: Dual-channel
- Supported memory clock speed (max): 7200 MHz
- ECC сompatibility: Non-ECC
Weight & dimensions:
- Depth: 244 mm
- Width: 244 mm
Network:
- Ethernet LAN: Yes
- Wi-Fi: No
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- Number of chassis fan connectors: 2
- Front panel audio connector: Yes
- S/PDIF out connector: Yes
- Number of SATA III connectors: 4
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- ATX Power connector (24-pin): Yes
- Number of COM connectors: 1
- CPU fan connector: Yes
- 12V power connector: Yes
- USB 2.0 connectors: 3
- RGB LED pin header: Yes
- EPS power connector (8-pin): Yes
- TPM connector: Yes
Packaging content:
- Screws included: Yes
- Cables included: SATA
Storage controllers:
- RAID levels: 1, 5, 0, 10
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
- Number of storage drives supported: 6
- RAID support: Yes
Rear panel I/O ports:
- Microphone in: Yes
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 4
- DisplayPorts quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- PS/2 ports quantity: 1
- HDMI ports quantity: 1
Expansion slots:
- Number of M.2 (M) slots: 2
- PCI Express x1 (Gen 4.x) slots: 1
- PCI Express x16 (Gen 4.x) slots: 2
