Leírás és Paraméterek
Processor:
- Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
- Processor socket: Socket AM5
- Processor manufacturer: AMD
- Supported processor sockets: Socket AM5
Features:
- Motherboard chipset family: AMD
- Motherboard chipset: AMD B840
- Windows operating systems supported: Windows 10 x64, Windows 11
- Motherboard form factor: micro ATX
- Audio output channels: 7.1 channels
Memory:
- Unbuffered memory: Yes
- Maximum internal memory: 192 GB
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Supported memory types: DDR5-SDRAM
- Number of memory slots: 4
- ECC сompatibility: ECC & Non-ECC
Weight & dimensions:
- Depth: 244 mm
- Width: 244 mm
Network:
- Bluetooth: Yes
- Wi-Fi: Yes
- Bluetooth version: 5.3
- Wi-Fi standards: Wi-Fi 6E (802.11ax)
- Ethernet interface type: 2.5 Gigabit Ethernet
- Ethernet LAN: Yes
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Internal I/O:
- Number of SATA III connectors: 4
- S/PDIF out connector: Yes
- TPM connector: Yes
- Front panel audio connector: Yes
- CPU fan connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- ATX Power connector (24-pin): Yes
- Number of chassis fan connectors: 3
- Front panel connector: Yes
- USB 2.0 connectors: 2
- Number of COM connectors: 1
- 12V power connector: Yes
Packaging data:
- Package weight: 1.52 kg
- Package depth: 275 mm
- Package height: 67.5 mm
- Package width: 275 mm
Packaging content:
- Cables included: SATA
- Screws included: Yes
- Antenna included: Yes
Storage controllers:
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
- RAID levels: 0, 5, 1, 10
- RAID support: Yes
- Number of storage drives supported: 7
- Number of HDDs supported: 4
Rear panel I/O ports:
- USB 2.0 ports quantity: 4
- DisplayPorts quantity: 2
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- HDMI ports quantity: 1
- WiFi-AP antenna jack: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
Expansion slots:
- PCI Express x16 (Gen 3.x) slots: 2
- Number of M.2 (M) slots: 3
- PCI Express x16 (Gen 4.x) slots: 1
- 2nd M.2 highest PCI Express generation: 4.0
- 2nd M.2 largest key size: 2280
- 1st M.2 largest key size: 2280
- 1st M.2 highest PCI Express generation: 4.0
- 3rd M.2 highest PCI Express generation: 3.0
- 3rd M.2 largest key size: 2280
