Leírás és Paraméterek
Processor:
- Processor socket: LGA 1700
- Compatible processor series: Intel® Core™ i5, Intel® Celeron®, Intel® Core™ i7, Intel® Core™ i9, Intel® Pentium® Gold, Intel® Core™ i3
- Processor manufacturer: Intel
- Supported processor sockets: LGA 1700
Features:
- Motherboard form factor: micro ATX
- Motherboard chipset: Intel H610
- Motherboard chipset family: Intel
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Audio output channels: 7.1 channels
Memory:
- Supported memory types: DDR5-SDRAM
- Memory slots type: DIMM
- Supported memory clock speed (max): 5600 MHz
- Number of memory slots: 2
- Memory channels: Dual-channel
- ECC сompatibility: Non-ECC
- Unbuffered memory: Yes
- Supported memory clock speeds: 5200, 5400, 4800, 5000, 5600
- Maximum internal memory: 96 GB
Weight & dimensions:
- Depth: 216 mm
- Width: 244 mm
Network:
- Wi-Fi standards: 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), 802.11a
- Ethernet LAN: Yes
- Bluetooth version: 5.0
- Ethernet interface type: Gigabit Ethernet
- Top Wi-Fi standard: Wi-Fi 5 (802.11ac)
- Wi-Fi: Yes
- Bluetooth: Yes
Internal I/O:
- Audio connector: Yes
- RGB LED pin header: Yes
- 12V power connector: Yes
- S/PDIF out connector: Yes
- ATX Power connector (24-pin): Yes
- Number of COM connectors: 1
- Number of SATA III connectors: 4
- CPU fan connector: Yes
- TPM connector: Yes
- USB 2.0 connectors: 2
- EPS power connector (8-pin): Yes
- Front panel audio connector: Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Number of chassis fan connectors: 2
BIOS:
- Clear CMOS button: Yes
- BIOS type: UEFI AMI
Packaging data:
- Package depth: 263 mm
- Package width: 270 mm
- Package height: 51.5 mm
- Package weight: 1.07 kg
Storage controllers:
- Number of HDDs supported: 4
- Number of storage drives supported: 6
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- WiFi-AP antenna jack: 1
- HDMI version: 2.1
- PS/2 ports quantity: 2
- Line-in: Yes
- HDMI ports quantity: 1
- VGA (D-Sub) ports quantity: 1
- Microphone in: Yes
- Headphone outputs: 1
- Ethernet LAN (RJ-45) ports: 1
- DisplayPort version: 1.4
- DisplayPorts quantity: 1
- USB 2.0 ports quantity: 4
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 1
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- PCI Express x1 (Gen 3.x) slots: 1
- Number of M.2 (M) slots: 2
