Leírás és Paraméterek
Processor:
- Compatible processor series: Intel Core i3 12th Gen, Intel Core i3 13th Gen, Intel Core i9 14th Gen, Intel® Pentium® Gold, Intel Core i5 12th Gen, Intel® Celeron®, Intel Core i7 12th Gen, Intel Core i5 14th Gen, Intel Core i5 13th Gen, Intel Core i9 12th Gen, Intel Core i7 13th Gen, Intel Core i9 13th Gen, Intel Core i3 14th Gen, Intel Core i7 14th Gen
- Processor manufacturer: Intel
- Supported processor sockets: LGA 1700
- Processor socket: LGA 1700
Graphics:
- DirectX version: 12.0
- Parallel processing technology support: Not supported
- HDCP: Yes
- Maximum resolution: 4096 x 2304 pixels
Features:
- Motherboard chipset: Intel B760 Express
- Product colour: Dark brown
- Audio chip: Realtek ALC897
- Audio output channels: 7.1 channels
- Power source type: ATX
- Motherboard chipset family: Intel
- PC health monitoring: Temperature, Water cooling, Voltage, Fan
- Windows operating systems supported: Windows 10 x64, Windows 11 x64
- Motherboard form factor: ATX
- Cooling type: Passive
Memory:
- Unbuffered memory: Yes
- Supported memory clock speeds: 4800, 4400, 5600, 5200
- Maximum internal memory: 256 GB
- Memory channels: Dual-channel
- Memory slots type: DIMM
- Number of memory slots: 4
- Supported memory types: DDR5-SDRAM
- Maximum internal memory per slot: 64 GB
- ECC сompatibility: ECC & Non-ECC
- Supported memory clock speed (max): 5600 MHz
Weight & dimensions:
- Height: 35 mm
- Width: 305 mm
- Depth: 244 mm
Network:
- LAN controller: Realtek RTL8111H
- Ethernet LAN: Yes
- Ethernet interface type: Gigabit Ethernet
- Wi-Fi: No
Internal I/O:
- S/PDIF out connector: Yes
- Number of SATA III connectors: 4
- Front panel connector: Yes
- CPU fan connector: Yes
- USB 2.0 connectors: 2
- TPM connector: Yes
- Serial port headers: 1
- ATX Power connector (24-pin): Yes
- EPS power connector (8-pin): Yes
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Front panel audio connector: Yes
- RGB LED pin header: Yes
- Number of chassis fan connectors: 4
- 12V power connector: Yes
- Number of water pump connectors: 2
- Number of CPU fan connectors: 2
- Number of RGB LED pin headers: 4
- Number of EPS power connectors (8-pin): 1
BIOS:
- BIOS type: UEFI AMI
- Desktop Management Interface (DMI) version: 2.7
- Clear CMOS jumper: Yes
Packaging data:
- Package weight: 1.5 kg
- Package height: 80 mm
- Package depth: 270 mm
- Package width: 335 mm
Packaging content:
- Batteries included: Yes
- Screws included: Yes
Storage controllers:
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, PCI Express 4.0, SATA III
- RAID levels: 5, 10, 0, 1
- Number of HDDs supported: 4
- Number of storage drives supported: 6
- RAID support: Yes
Rear panel I/O ports:
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- DisplayPort version: 1.2
- DisplayPorts quantity: 1
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 4
- HDMI ports quantity: 1
- Microphone in: Yes
- Line-in: Yes
- HDMI version: 2.1
- Headphone outputs: 1
- PS/2 ports quantity: 1
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
Expansion slots:
- PCI Express x16 (Gen 3.x) slots: 4
- Number of M.2 (M) slots: 2
- 2nd M.2 largest key size: 2280
- 1st M.2 largest key size: 2280
- 1st M.2 highest PCI Express generation: 4.0
- 2nd M.2 highest PCI Express generation: 4.0
- PCI Express x16 (Gen 5.x) slots: 1
Battery:
- Battery type: CR2032
- Battery technology: Lithium-Manganese Dioxide (LiMnO2)
- Battery weight: 3 g
- Number of battery cells: 1
- Lithium weight per battery: 0.07 g
Logistics data:
- Country of origin: China
- Products per shipping (inner) case: 1 pc(s)
