Processor:
- Compatible processor series: AMD Ryzen 3000 Series, AMD Athlon
- Maximum number of SMP processors: 1
- Processor manufacturer: AMD
- Processor socket: Socket AM4
Features:
- Motherboard chipset: AMD B550
- Audio chip: Realtek ALC887 / Realtek ALC897
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 10 x64
- Motherboard chipset family: AMD
- Motherboard form factor: micro ATX
- Component for: PC
Memory:
- Supported memory clock speeds: 3600, 3733, 4400, 3000, 3866, 2133, 3466, 4600, 2400, 2800, 3333, 4466, 3200 MHz, 2666, 4266, 4133, 4000 MHz, 4800
- Memory slots type: DIMM
- Number of memory slots: 4
- Maximum internal memory: 128 GB
- Memory channels: Dual-channel
- Unbuffered memory: Yes
- Supported memory types: DDR4-SDRAM
- ECC сompatibility: ECC
Weight & dimensions:
- Height: 51 mm
- Depth: 244 mm
- Width: 244 mm
Network:
- Ethernet interface type: Gigabit Ethernet
- Ethernet LAN: Yes
- Wake-on-LAN ready: Yes
- LAN controller: Realtek RTL8111H
Internal I/O:
- Chassis intrusion connector: Yes
- Front panel audio connector: Yes
- CPU fan connector: Yes
- Number of COM connectors: 1
- USB 2.0 connectors: 2
- Number of chassis fan connectors: 2
- 12V power connector: Yes
- Number of EATX power connectors: 1
- ATX Power connector (24-pin): Yes
- Number of SATA III connectors: 4
- Thunderbolt headers: 1
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
BIOS:
- BIOS type: UEFI AMI
- Clear CMOS jumper: Yes
- BIOS memory size: 256 Mbit
Packaging content:
- Cables included: SATA
- Drivers included: Yes
Storage controllers:
- Supported storage drive interfaces: SATA III
- RAID levels: 0, 10, 1
- Supported storage drive types: HDD & SSD
Rear panel I/O ports:
- DisplayPorts quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- HDMI ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- PS/2 ports quantity: 2
- HDMI version: 2.1
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- USB 2.0 ports quantity: 2
Expansion slots:
- PCI Express x4 slots: 1
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 2
- PCI slots: 1
