Leírás és Paraméterek
Processor:
- Supported processor sockets: Socket AM5
- Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 8000 Series, AMD Ryzen 7000 Series
- Processor socket: Socket AM5
- Processor manufacturer: AMD
Features:
- Motherboard chipset family: AMD
- Motherboard form factor: ATX
- Motherboard chipset: AMD B650
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 10 x64, Windows 11
Memory:
- ECC сompatibility: ECC & Non-ECC
- Supported memory clock speed (max): 7600 MHz
- Supported memory clock speeds: 6400, 5800, 5400, 7600 MHz, 7800, 5000, 6800, 6200, 7400, 5200 MHz, 6600, 7000, 6000, 4800, 5600, 7200
- Unbuffered memory: Yes
- Maximum internal memory: 192 GB
- Memory slots type: DIMM
- Supported memory types: DDR5-SDRAM
- Memory channels: Dual-channel
- Number of memory slots: 4
Weight & dimensions:
- Width: 305 mm
- Depth: 244 mm
Network:
- Bluetooth: Yes
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
- Wi-Fi: Yes
- Wi-Fi standards: Wi-Fi 6E (802.11ax)
- Ethernet LAN: Yes
- Bluetooth version: 5.3
- Ethernet interface type: 2.5 Gigabit Ethernet
Internal I/O:
- Number of CPU fan connectors: 2
- Number of RGB LED pin headers: 1
- Number of SATA III connectors: 4
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- Thunderbolt headers: 1
- USB 2.0 connectors: 2
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 2
- Front panel audio connector: Yes
- Number of COM connectors: 1
- RGB LED pin header: Yes
- TPM connector: Yes
- Front panel connector: Yes
- EPS power connector (8-pin): Yes
- 12V power connector: Yes
- Number of chassis fan connectors: 3
Packaging data:
- Package weight: 1.35 kg
- Package height: 68 mm
- Package width: 338 mm
- Package depth: 373 mm
Packaging content:
- Antenna included: Yes
- Screws included: Yes
- Cables included: SATA
Storage controllers:
- Supported storage drive types: HDD & SSD
- RAID support: Yes
- RAID levels: 10, 1, 0
- Supported storage drive interfaces: M.2, SATA III
- Number of HDDs supported: 4
- Number of storage drives supported: 6
Rear panel I/O ports:
- DisplayPorts quantity: 1
- S/PDIF out port: Yes
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 2
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- WiFi-AP antenna jack: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 3
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Expansion slots:
- 1st M.2 largest key size: 22110
- 1st M.2 highest PCI Express generation: 5.0
- 2nd M.2 highest PCI Express generation: 4.0
- 2nd M.2 largest key size: 22110
- PCI Express x16 (Gen 4.x) slots: 2
- PCI Express x1 (Gen 4.x) slots: 2
- Number of M.2 (M) slots: 2
