Processor:
- Compatible processor series: AMD Ryzen 7000 Series
- Processor manufacturer: AMD
- Processor socket: Socket AM5
- Supported processor sockets: Socket AM5
Features:
- Audio output channels: 7.1 channels
- Windows operating systems supported: Windows 11 x64, Windows 10
- Motherboard chipset: AMD B650
- Motherboard chipset family: AMD
- Audio chip: Realtek ALC4080
- Power source type: ATX
- Motherboard form factor: ATX
Memory:
- Memory channels: Dual-channel
- Unbuffered memory: Yes
- Memory slots type: DIMM
- Supported memory clock speeds: 6000, 6200, 5600, 5200, 5000, 4800, 6400, 5800, 5400
- Supported memory types: DDR5-SDRAM
- Maximum internal memory: 128 GB
- Number of memory slots: 4
- Supported memory clock speed (max): 6400 MHz
- ECC сompatibility: ECC & Non-ECC
Weight & dimensions:
- Depth: 244 mm
- Width: 305 mm
Network:
- Wi-Fi: Yes
- Wi-Fi standards: Wi-Fi 6E (802.11ax), 802.11a, Wi-Fi 6 (802.11ax), 802.11g, 802.11b, Wi-Fi 5 (802.11ac), Wi-Fi 4 (802.11n)
- Ethernet interface type: 2.5 Gigabit Ethernet
- Bluetooth version: 5.2
- Bluetooth: Yes
- Ethernet LAN: Yes
- Top Wi-Fi standard: Wi-Fi 6E (802.11ax)
Internal I/O:
- USB 3.2 Gen 2 (3.1 Gen 2) connectors: 1
- Thunderbolt headers: 1
- EPS power connector (8-pin): Yes
- Number of SATA III connectors: 4
- RGB LED pin header: Yes
- Number of chassis fan connectors: 5
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- CPU fan connector: Yes
- USB 2.0 connectors: 2
- Front panel audio connector: Yes
- 12V power connector: Yes
- ATX Power connector (24-pin): Yes
BIOS:
- BIOS type: UEFI AMI
- Clear CMOS button: Yes
Packaging data:
- Package width: 343 mm
- Package depth: 273 mm
- Package height: 77 mm
- Package weight: 2.44 kg
Packaging content:
- Cables included: SATA
- User guide: Yes
Storage controllers:
- RAID levels: 10, 0, 1
- Supported storage drive types: HDD & SSD
- Supported storage drive interfaces: M.2, SATA III
- RAID support: Yes
Rear panel I/O ports:
- Headphone outputs: 1
- S/PDIF out port: Yes
- Line-in: Yes
- DisplayPorts quantity: 1
- DisplayPort version: 1.4
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 6
- HDMI ports quantity: 1
- HDMI version: 2.1
- Microphone in: Yes
- USB 2.0 ports quantity: 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- USB 3.2 Gen 2x2 Type-C ports quantity: 1
Expansion slots:
- PCI Express x16 (Gen 4.x) slots: 1
- Number of M.2 (M) slots: 4
- PCI Express x16 (Gen 5.x) slots: 2
