Leírás és Paraméterek
Processor:
- Supported processor sockets: Socket AM5
- Processor manufacturer: AMD
- Processor socket: Socket AM5
- Compatible processor series: AMD Ryzen 9000 Series, AMD Ryzen 7000 Series, AMD Ryzen 8000 Series
Features:
- Motherboard chipset family: AMD
- Motherboard form factor: ATX
- Motherboard chipset: AMD X870E
Memory:
- Memory channels: Dual-channel
- Supported memory types: DDR5-SDRAM
- Number of memory slots: 4
- ECC сompatibility: Non-ECC
- Maximum internal memory: 256 GB
Weight & dimensions:
- Depth: 243.8 mm
- Width: 304.8 mm
Network:
- Wi-Fi standards: 802.11a, Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax), 802.11g, Wi-Fi 5 (802.11ac), Wi-Fi 7 (802.11be), 802.11b, Wi-Fi 4 (802.11n)
- Top Wi-Fi standard: Wi-Fi 7 (802.11be)
- Bluetooth version: 5.4
- Ethernet LAN: Yes
- Wi-Fi: Yes
- Bluetooth: Yes
Internal I/O:
- Number of chassis fan connectors: 6
- USB 3.2 Gen 2 (3.1 Gen 2) Type-C ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 4
- TPM connector: Yes
- Number of SATA III connectors: 4
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- RGB LED pin header: Yes
- Number of CPU fan connectors: 1
- USB 2.0 connectors: 6
Storage controllers:
- RAID levels: 1, 10, 5, 0
- RAID support: Yes
- Supported storage drive interfaces: M.2, SATA III
Rear panel I/O ports:
- Ethernet LAN (RJ-45) ports: 1
- USB 2.0 ports quantity: 4
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 2
- HDMI version: 2.1
- HDMI ports quantity: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
- Number of USB 3.2 Gen 2x2 (3.1 Gen 2x2) Type-C ports : 1
- USB4 Gen 3x2 ports quantity: 1
Expansion slots:
- PCI Express x16 (Gen 3.x) slots: 3
- PCI Express x1 slots: 1
