Leírás és Paraméterek
Processor:
- Maximum number of SMP processors: 1
- Processor manufacturer: AMD
- Processor socket: Socket AM4
- Compatible processor series: 3rd Generation AMD Ryzen™ 9, 3rd Generation AMD Ryzen 5, 3rd Generation AMD Ryzen™ 7, 3rd Generation AMD Ryzen™ 3
Features:
- Cooling type: Active
- Motherboard chipset family: AMD
- Audio output channels: 8 channels
- Windows operating systems supported: Windows 7 x64, Windows 10 x64
- Number of mounting holes: 8
- Power source type: ATX
- Motherboard chipset: AMD B450
- Audio chip: Realtek ALC S1200A
- Motherboard form factor: ATX
Memory:
- Memory slots type: DIMM
- Supported memory clock speeds: 3400, 3866, 3200, 2666, 3466, 3533, 3000, 3600, 2400, 2800, 3733, 4400, 2133, 4000
- Maximum internal memory: 128 GB
- Memory channels: Dual-channel
- Unbuffered memory: Yes
- Number of memory slots: 4
- Supported memory types: DDR4-SDRAM
Weight & dimensions:
- Depth: 244 mm
- Width: 305 mm
Network:
- LAN controller: Realtek L8200A
- Ethernet LAN: Yes
- Ethernet interface type: Gigabit Ethernet
- Wi-Fi: No
Internal I/O:
- USB 3.2 Gen 1 (3.1 Gen 1) connectors: 1
- Number of EATX power connectors: 1
- ATX Power connector (24-pin): Yes
- CPU fan connector: Yes
- Number of SATA III connectors: 6
- TPM connector: Yes
- S/PDIF out connector: Yes
- Total number of SATA connectors: 6
- RGB LED pin header: Yes
- Audio connector: Yes
- USB 2.0 connectors: 2
- Front panel audio connector: Yes
- Number of COM connectors: 1
- Number of chassis fan connectors: 2
BIOS:
- BIOS type: UEFI AMI
- Clear CMOS jumper: Yes
Packaging content:
- Cables included: SATA
- Drivers included: Yes
Storage controllers:
- Supported storage drive types: HDD & SSD
- RAID levels: 0, 10, 1
- Supported storage drive interfaces: M.2, Serial ATA
Rear panel I/O ports:
- DisplayPorts quantity: 1
- DisplayPort version: 1.2
- HDMI ports quantity: 1
- USB 2.0 ports quantity: 2
- USB connector type: USB Type-A, USB Type-C
- USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity: 1
- USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity: 1
- HDMI version: 2.0b
- Ethernet LAN (RJ-45) ports: 1
- USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity: 2
Expansion slots:
- PCI Express x16 (Gen 3.x) slots: 1
- Number of M.2 (M) slots: 1
- PCI Express x1 (Gen 2.x) slots: 3
